Panasonic Lumix DMC-LX100 User Manual

185
SQW0021
Stabilizer, Zoom and Flash
Taking pictures using the flash (supplied)
2
Set the menu
→ [Rec] → [Flash] → [Wireless]
3
Press to select [ON] and press [MENU/SET]
• When [Wireless] is set to [ON], [WL] will appear with the flash icon on the recording screen.
• To perform detailed settings for the wireless flash, perform the following settings from the [Flash].
4
Press to select [Wireless Channel] and press
[MENU/SET]
Firing Mode Flash output
Luminosity ratio
5
Press to select the channel and press [MENU/SET]
• Select the same channel as the channel set for the wireless flash
in step
1
.
6
Press to select [Wireless Setup] and press
[MENU/SET]
7
Use to select the item and press [MENU/SET]
• Press the [DISP.] button to perform a test firing.
[External
Flash]
[Firing
Mode]
[TTL]: The camera automatically sets the flash output.
[AUTO]
*
: Sets the flash output using an external flash.
[MANUAL]: Manually sets the flash ratio of an external flash.
[OFF]: An external flash fires only for a communication light emission.
[Flash
Adjust.]
Adjusts the flash output of an external flash manually when [Firing
Mode] is set to [TTL].
[Manual
Flash
Adjust.]
Sets the flash ratio of an external flash when [Firing Mode] is set to
[MANUAL].
• You can set the flash ratio from [1/1] (flash firing full power) to [1/64]
in 1/3 steps.
[A Group]/
[B Group]/
[C Group]
[Firing
Mode]
[TTL]: The camera automatically sets the wireless flash output.
[AUTO]: Sets the flash output using the wireless flash.
[MANUAL]: Manually sets the flash ratio of the wireless flash.
[OFF]: The wireless flashes of the set group do not fire.
[Flash
Adjust.]
Adjusts the flash output of the wireless flash manually when [Firing
Mode] is set to [TTL].
[Manual
Flash
Adjust.]
Sets the flash ratio of the wireless flash when [Firing Mode] is set to
[MANUAL].
• You can set the flash ratio from [1/1] (flash firing full power) to [1/64]
in 1/3 steps.
*
When the flash (supplied) is attached to this unit, you cannot perform these settings.

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
