12 VQT1B61
Camera ON/OFF switch
(P.18)
Optical image stabilizer
button (P.39)
Lens barrel
Lens (P.11)
Self-timer
indicator
(P.35)/AF
assist lamp
(P.56)
Release lever (P.15)
Names of parts
Shutter button (P.24)
Zoom lever (P.27)
Flash (P.36)
Speaker (P.22)
Microphone
(P.47, 53, 70)
Status indicator (P.15, 24)
DISPLAY/LCD MODE
button (P.33, 34)
FUNC (Quick setting P.57)/
delete (P.32) button
Tripod receptacle
Card/Battery door (P.15)
DIGITAL/AV OUT socket
(P.74, 76, 79)
DC IN socket (P.74, 76)
Always use a genuine Panasonic AC
adaptor (DMW-AC5PP: optional).
LCD monitor
● Checking remaining battery/
memory capacity, etc (P.25)
● Changing display (P.33)
● Display contents list (P.80)
Strap
(supplied)
