Panasonic NA-F135X1

CONTENT
1. Attention in the Repair Work Security 3
 2. PartsIdentication 4
 3. Specications 5
4. Technical Information
4.1 Standard Wash Capacity 6
4.2 Standard Water Supply 6
5. Installation
5.1 Check the Location 7
5.2 Attach the bottom cover 7
5.3 Attach the external drain water hose 7
5.4 Connect the water tap adaptor and water supply hose 8
5.5 Connect the power plug and grounding wire 8
5.6 Check the Washing Machine is level 8
5.7 Perform a trial operation 8
6. Operations Panel 9
7. Washing 10
8. Washing Options 11
9. Maintenance 12
10. Test Mode 13 - 14
11. Troubleshooting 15
12. Table of Errors
12.1 U-Error indication 16
12.2 H-Error indication 17
13. Wiring Diagram
13.1 NA-F135X1, NA-F115X1 18
13.2 NA-F135A1, NA-F125A1, NA-F115A1 18
14. Disassembly
14.1 Controller Unit 19
14.2 Panel Face B 19
15. Parts exploded view and replacement Parts List
15.1 Parts exploded view : Part A 20
15.2 Replacement Parts List : Part A 21
15.3 Parts exploded view : Part B 22
15.4 Replacement Parts List : Part B 23
15.5 Parts exploded view : Part C 24
15.6 Replacement Parts List : Part C 25
15.7 Parts exploded view : Packing 26
15.8 Replacement Parts List : Packing 27
- 2 -
