Panasonic NN-GD366M - Quartz Heater Replacement; H.V. Inverter Power Supply Replacement

4.7. Quartz heater
1. Disconnect lead wires from heater terminals.
2. Remove 1 screw holding heater supports.
3. Remove the heater by pulling it out.
4.8. H.V. Inverter Power Supply
1. Remove the H.V. lead wire from magnetron terminals.
2. Disconnect 2 connectors from CN701 & CN702 on H.V.
inverter (U).
3. Remove 1 screw holding grounding plate on the base.
4. Remove 1 screw holding inverter bracket on the base.
5. Slide 2 locking tabs of inverter bracket at the bottom of the
base in direction of arrows.
6. Remove 2 screws holding H.V. inverter to the inverter
bracket.
12
NN-GD376S / NN-GD366M / NN-GD356W
