Panasonic NN-GD366M - 8 EXPLODED VIEW AND PARTS LIST; 8.2. General Component Parts List

8.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
2 F10017K10XPG BASE 1
3 F10084T00AP RUBBER FOOT 2
4 F110D6N60SXP CABINET BODY 1 GD376S
4 F110D8H10SXP CABINET BODY 1 GD366M
4 F110D6N60HXP CABINET BODY 1 GD356W
5 F200A8H00XP OVEN 1
6 F20556S10XP COVER 1
7 F21316E70XP PULLY SHAFT 1
8 F2177-F80 WASHER 1
9 F290D6S10XP ROLLER RING (U) 1
10 F3020-1200 DOOR HOOK 1
11 F3136-1200 HOOK LEVER A 1
12 F31374650AP HOOK LEVER B 1
13 F31384650AP HOOK LEVER C 1
14 F400A6S10XP FAN MOTOR 1
15 F4008-1E60 FAN BLADE 1
16 F40258H00XP AIR GUIDE A 1
17 F41446S10XP ORIFICE 1
18 F612E5G50XN INCANDESCENT LAMP (U) 1
19 J61415G10XN MICRO SWITCH 1 V-15G-3C25 (PRIMARY LATCH SWITCH)
20 J61414T00AP MICRO SWITCH 1 D3V-16G-3C25 (SECONDARY LATCH SWITCH)
21 F61785U30XN SHORT SWITCH 1 D3V-1G-2C25 (SHORT SWITCH)
22 2M261-M22J3Y MAGNETRON 1
23 F606YM300BP H.V.INVERTER(U) 1
24 F65857K10XP INVERTER BRACKET 1
25 F66627K10XP GROUNDING PLATE 1
27 F62306V60BP FUSE 1 10A,250V
29 F63266S30XP TURNTABLE MOTOR 1
30 F900C8H00BP AC CORD W/PLUG 1 BPQ
30 F900C7K10ZP AC CORD W/PLUG 1 EPG
30 F900C8H20WP AC CORD W/PLUG 1 WPG
31 F61456N60AP THERMAL CUTOUT 1 -20°C ON ,150°C OFF
32 F21766S10XP SEAL 1
33 F11656S10XP REINFORCE BRACKET 1
35 F64605G50XN HEATER MOUNTING PLATE 2
36 F630G5G50BP HEATER (AU) 2
38 F40268920XN AIR GUIDE B 1
39 F692Y8H00BP NOISE FILTER (U) 1
41 F11407000AP STOPPER 1
42 F01506W50XP NO TOUCHING LABEL 1 EPG,WPG
44 F22175G60APG INSULATE BRACKET 1
45 XTWFA4+12T SCREW 4 FOR MAGNETRON
46 XTWFA4+12D SCREW 3 FOR CABINET BODY
47 XTTFA4+6BN SCREW 2 FOR CABINET BODY SIDE
48 F01505G50BP NO TOUCHING LABEL 1 BPQ
49 F02395G50BP AC CORD CAUTION LABEL 1 BPQ
50 F04908H00SEP ENERGY LABEL 1 GD376S EPG
50 F04908H10SEP ENERGY LABEL 1 GD366M EPG
50 F04908H20HEP ENERGY LABEL 1 GD356M EPG
51 F00064080BP CAUTION LABEL 1 BPQ
51 F00069000EP CAUTION LABEL 1 EPG,WPG
22
NN-GD376S / NN-GD366M / NN-GD356W
