No. ITEM/PART FIGURE REMARKS
18 OUTER SIDE
PLATE-S
Fig. D16
2-Screws (P)
19 SUB
RACK/S-MAIN
RACK
Fig. D17
20 TOP PLATE
Fig. D18
2-Screws (Q)
21 SIDE PLATE
S& T/GUARD
PANEL /
CASSETTE
HOLDER
UNIT/FRONT
GUIDE/BLIND
LEVER
Fig. D19
Fig. D9-1
Fig. D9-2
