2. GENERAL DESCRIPTIONS
2.1. SERVICE POSITION
2.1.1. Extension Cables
Use the following Extension Cables when checking individual circuit boards.
No. Part No. Part Name Connection
Q‘ty
Remarks
1 VFK1507P ANALOG Y/C Connection
C.B.A.
Main C.B.A.
→
Analog Y/C
C.B.A.
1
2 VFK1509 36P Flat Cable
Main FP3401
→
Digital FP3201
1
3 VFK1508 32P Flat Cable
Main FP3402
→
Digital FP3202
1
4 VFK1509 36P Flat Cable
Main FP6201
→
Digital FP6002
1
5 VFK1174 30P Flat Cable
Digital FP6003
→
Mech. Flex.
(VES0914)
1
6 VFK1284 24P Flat Cable
Digital FP3203
→
Mech. (Head
Amp)
1
7 VFK1292 9P Flat Cable
Digital P2501
→
Mech.
(Cylinder)
1
8 VFK1282 22P Flat Cable
Digital P2502
→
Mech.
(Capstan)
1
9 VFK1446 32P Flat Cable
Main P7901
→
Timer P7502
1
10 VFK1445 26P Flat Cable
Main P7902
→
Timer P7501
1
11 VFK1527 3P Extension Cable
Digital P6001
→
Switch P1502
1
12 VFK1529 2P Extension Cable
Digital P6002
→
Motor P1501
1
13 VFK1530 30P Flat Cable Mech. Flex. (VES0914) 1 for Emagency Tape
Ejection
Fig. 2-1 Extension Cable
2.1.2. Service Position
2.1.2.1. Service Position for Analog Y/C C.B.A.
Fig. 2-2 Service Position for Analog Y/C C.B.A.
