(FOIL SIDE)
(COMPONENT SIDE)
A
B
C
D
1
24
3
5
678
POWER
EJECT
STEREO
SELECT
Q7501 A-4
Q7502 A-3
QR7501 A-3
QR7502 A-3
IC7501 B-5
IC7502 B-4
IC7503 B-2
IC7504 D-4
TL4801 B-3
TL4802 B-2
TL7501 A-5
TL7502 B-5
TL7503 B-5
TL7505 A-6
TL7506 B-6
TL7509 B-6
TL7510 B-6
VR4801 B-3
VR4802 B-2
P7501 B-2
P7502 B-7
P7503 B-6
ADDRESS INFORMATION
Test Land
Adjstment
Connector
TIMER C.B.A.
Transistor
Transistor & Resistor
Integrated Circuit
Precautions for maintenance of timer/main C.B.A.
Disconnection of the flexible cable between P7502 and P7901 for
maintenance or check of the timer/main C.B.A. without applying any voltage
will cause the loss of the back up +B of the timer microcomputer. Be sure to
apply a voltage of +4.5 V to the connector of P7503 before disconnecting the
flexible cable.
If the back up +B is lost, the CH setting and data of the timer will be initialized
AUDIO
OUT
Back up battery terminal (1.5 X3)
8mm
CONTROL
EDIT
DV F/R SW
S IN
LINE IN
EDIT MODE 1
EDIT MODE 2
MIX LED
SP/LP/ELP
TBC
3 DNR
PRINT
S OUT
LINE OUT
MIX
IN SEL
REC
STILL
FF
PLAY
STOP
REW
REC
STILL
ALBUM
To Next Page
