Panasonic NV-MD10000GC - Disassembly Procedures

17
8.3. Disassembly Procedures
Flow-Chart for Disassembly Procedure
No. Item / Part Fig. Removal (Screw,Connector,Flex. &
Other)
1 Side Case (R)
Unit
Fig.D1 8-Screws (A)
Face Panel
Shoulder Pad
Fig.D2 1-Screw (B)
4-Tabs
ND-Filter Case Unit
Fig.D3 3-Screws (C)
Focus Ring
Fig.D4 3-Screws (D), 4-Screws (E), 4-Screws
(F)
1-Connector FP6418
Side Case (R) Unit
2 Lens Unit Fig.D5 4-Screws (G)
2-Connectors P6406, P6408
Fig.D6 3-Screws (H)
3-Connectors FP6401, FP6404,
PS6417
Fig.D7 1-Screw (I), 2-Screws (J)
MF Ring Unit, Lens Unit
3 Mother P.C.B. Fig.D8 4-Screws (K)
14-Connectors P6411, P6412, P6420,
P6424, FP6402, FP6405, FP6407,
FP6409, FP6410, FP6413, FP6414,
FP6415, FP6416, FP6419
Mother P.C.B.
4 Main P.C.B. Fig.D9 4-Screws (L)
Grip Cover Unit
Fig.D10 2-Screws (M), 2-Screws (N)
Cassette Cover Unit
3-Screws (O), 2-Screws (P)
1-Connector P6751
EVR Int P.C.B., Side Case (L) Unit
Fig.D11 1-Screw (Q)
5-Connectors FP2201, FP2202,
FP2203, FP2204, FP5001
Mecha Frame Unit
Main P.C.B.
5 Mecha Unit Fig. D12 3-Screws (R)
Mecha Unit
6 Handle/EVF
Unit
Fig.D13 2-Screws (S)
Handle Unit
1-Screw (T)
Accesories Shoe Spring
4-Screws (U)
Shoe Hold Plate
Fig. D14 2-Screws (V)
Mic Unit
Fig. D15 2-Screws (W)
Slide Cover
3-Screws (X)
EVF Unit
7 EVF Int P.C.B. Fig.D16 2-Screws (Y)
EVF Ring, EVF Lock Ring
Fig.D17 EVF Cap
Fig.D18 4-Screw (Z)
5-Tabs
EVF Case Top, EVF Case Bottom
Fig.D19 1-Connector FP6852
EVF/LCD Unit
3-Screws (a)
EVF Int P.C.B.
8 EVF P.C.B. Fig.D20 1-Connector FP802
EVF P.C.B.
9 Zoom P.C.B. Fig.D21 3-Screws (b)
Grip Cover
Fig.D22 1-Screw (c)
1-Connector FP6651
Zoom P.C.B.
10 Front P.C.B. Fig.D23 2-Screws (d)
Remocon Sensor Window
Fig.D24 2-Screws (e)
Front P.C.B.
11 S/S Power
P. C. B.
Fig.D25 3-Screws (f)
Grip op Unit
Fig.D26 3-Screws (g)
S/S Power P.C.B.
12 AV Jack P.C.B. Fig.D27 3-Screws (h), 2-Screws (i), 1-Screw (j)
Side Case (L)
Fig.D28 4-Screws (k), 1-Screw (l), 1-Screw (m),
1-Screw (n)
L Earth Plate B
Fig.D29 2-Screws (o)
AV Jack Plate, AV Jack P.C.B.
13 Battery Int
P. C. B.
Fig.D30 4-Screws (p)
Battery Case Unit
Fig.D31 2-Screws (q)
1-Connector FP6751
Battery Holder, Battery Int P.C.B.
14 LCD Unit Fig.D32 6-Screws (r)
Hinji Earth Plate
1-Screw (s)
LCD Unit
15 Monitor P.C.B. Fig.D33 2-Screws (t)
LCD Hinji Holder, Hinji Support Plate
Fig.D34 2-Screws (u)
4-Tabs
LCD Case Top Unit, LCD Hinji Unit
Fig.D35 LCD Frame
1-Connector FP901
Monitor P.C.B.
No. Item / Part Fig. Removal (Screw,Connector,Flex. &
Other)
