Panasonic NV-MD10000GC - S3. Block Diagram; S3.1. Overall Block Diagram

S-2
S2. Voltage Chart
S2.1. Monitor P.C.B.
REF No. PIN No. REC PB EE
QR6401 1 0 0 0
QR6401 2 2.9 2.9 2.9
QR6401 3 2.9 2.9 2.9
QR6401 4 0 0 0
QR6401 5 0 0 0
QR6401 6 0 0 0
S2.2. EVF P.C.B.
REF No. PIN No. REC PB EE
Q801 E 0.6 0.6 0.6
Q801 C 1.7 1.7 1.7
Q801 B 1.3 1.3 1.3
S2.3. Mic Jack P.C.B.
REF No. PIN No. REC PB EE
Q4901 E 0.4 0.4 0.4
Q4901 C 3.5 3.5 3.5
Q4901 B 0.9 0.9 0.9
Q4902 E 4.9 4.9 4.9
Q4902 C 2.3 2.3 2.3
Q4902 B 3.5 3.5 3.5
Q4903 E 0.4 0.4 0.4
Q4903 C 3.5 3.5 3.5
Q4903 B 0.9 0.9 0.9
Q4904 E 4.9 4.9 4.9
Q4904 C 2.2 2.2 2.2
Q4904 B 3.5 3.5 3.5
Q4905 E 4.9 4.9 4.9
Q4905 C 4.9 4.9 4.9
Q4905 B 4.2 4.2 4.2
Q4906 E 0 0 0
Q4906 C 0 0 0
Q4906 B 4.9 4.9 4.9
S2.4. Front P.C.B.
REF No. PIN No. REC PB EE
Q6801 E 3.7 3.7 3.7
Q6801 C 4.9 4.9 4.9
Q6801 B 3.4 3.4 3.4
Q6802 E 3.2 3.2 3.2
Q6802 C 4.9 4.9 4.9
Q6802 B 3.7 3.7 3.7
