Specifications
75
VQT0S76
Specifications
Specifications
Digital Video Camera
Information for your safety
Recording format:
Mini DV (Consumer-use digital video SD format)
Tape used:
6.35 mm digital video tape
Recording/playback time:
SP: 80 min; LP: 120 min (with DVM80)
Video
Recording system:
Digital component
Television system:
CCIR: 625 lines, 50 fields PAL colour signal
Audio
Recording system:
PCM digital recording
16 bit (48 kHz/2 ch), 12 bit (32 kHz/4 ch)
Image sensor:
1/6-inch 3CCD image sensor
(Effective pixels: moving picture/340 K
k3, Total: 540 Kk3)
Lens:
Auto Iris, F1.8 to F2.8, Focal length; 2.45 mm to 24.5 mm,
Macro (Full range AF)
Filter diameter:
43 mm
Zoom:
10:1 Power zoom
Monitor:
2.5-inch LCD
Viewfinder:
Colour electronic viewfinder
Microphone:
Stereo (with a zoom function)
Speaker:
1 round speaker
‰ 20 mm
Standard illumination:
1,400 lx
Minimum required illumination:
1 lx (Colour Night View Mode)
Video output level:
1.0 Vp-p, 75
h
S-Video output level:
Y Output: 1.0 Vp-p, 75
h
C Output: 0.3 Vp-p, 75 h
Audio output level (Line):
316 mV, 600
h
Mic input:
Mic sensitivity –50 dB (0 dB=1 V/Pa, 1 kHz) (Stereo mini jack)
Digital interface:
DV input/output terminal (IEEE1394, 4-pin)
Dimensions:
Approx. 216 mm (W)
k225 mm (H)k432 mm (D)
(excluding the projection part)
Mass:
Approx. 2000 g (without supplied battery, DV cassette and lens cap)
Approx. 2120 g (with supplied battery, DV cassette and lens cap)
Operating temperature:
0
oC to 40 oC
Operating humidity:
10% to 80%
AC adaptor VSK0644
Information for your safety
Dimensions:
70 mm (W)
k45 mm (H)k116 mm (D)
Mass:
Approx. 165 g
Weight and dimensions are approximate values.
Specifications may change without prior notice.
Power source:
DC 7.9/7.2 V
Power consumption:
Recording
3.0 W (When using viewfinder)
3.3 W (When using LCD monitor)
Power source:
AC 110 V to 240 V, 50/60 Hz
Power consumption:
20 W
DC output:
DC 7.9 V, 9 W (Movie camera operation)
DC 8.4 V, 1.2 A (Battery charging)
