Panasonic PT-AE2000U - Page 76

Ref.
No.
Part No. Part Name & Description Remarks
R1481 EXB38V470JV RESISTOR ARRAY
R1482 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1483 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1484 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1485 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1486 EXB28VR000 RESISTOR ARRAY
R1487 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1488 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1489 EXB38V470JV RESISTOR ARRAY
R1490 EXB38V470JV RESISTOR ARRAY
R1491 EXB38V470JV RESISTOR ARRAY
R1492 EXB38V470JV RESISTOR ARRAY
R1493 EXB38V470JV RESISTOR ARRAY
R1494 EXB38V470JV RESISTOR ARRAY
R1495 EXB38V470JV RESISTOR ARRAY
R1496 EXB38V470JV RESISTOR ARRAY
R1497 EXB38V470JV RESISTOR ARRAY
R1498 EXB38V470JV RESISTOR ARRAY
R1499 EXB38V470JV RESISTOR ARRAY
R1500 EXB38V470JV RESISTOR ARRAY
R1501 EXB38V470JV RESISTOR ARRAY
R1502 EXB38V470JV RESISTOR ARRAY
R1503 EXB38V470JV RESISTOR ARRAY
R1504 EXB38V470JV RESISTOR ARRAY
R1505 EXB38V470JV RESISTOR ARRAY
R1506 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1507 EXB38V470JV RESISTOR ARRAY
R1508 EXB38V470JV RESISTOR ARRAY
R1509 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1510 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1511 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1512 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1513 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1514 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1515 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1517 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1518 ERJ3EKF2200 M 220 OHM, 1/16W
R1519 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1520 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1521 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1522 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1523 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1524 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1525 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1526 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1527 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1528 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1529 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1530 EXB28VR000 RESISTOR ARRAY
R1531 EXB28VR000 RESISTOR ARRAY
R1532 EXB28VR000 RESISTOR ARRAY
R1533 EXB28VR000 RESISTOR ARRAY
R1534 EXB28VR000 RESISTOR ARRAY
R1535 ERJ2GEJ103 M 10K OHM, 0.063W
R1537 EXB28VR000 RESISTOR ARRAY
R1538 EXB28VR000 RESISTOR ARRAY
R1539 EXB28VR000 RESISTOR ARRAY
R1540 EXB28VR000 RESISTOR ARRAY
R1542 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1543 ERJ3GEYJ470 M 47 OHM,J,1/16W
R1544 ERJ2GEJ223 RESISTOR
R1545 ERJ2GEJ472 M 4.7KOHM, 0.063W
R1550 ERJ3GEYJ473 M 47K OHM,J,1/16W
R1553 ERJ3EKF4992 RESISTOR
R1554 ERJ3GEYJ272 M 2.7KOHMJ,J1/16W
R1555 ERJ3EKF1002 M 10KOHM, 1/16W
R1556 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1559 ERJ3GEYJ473 M 47K OHM,J,1/16W
R1560 ERJ3GEYJ473 M 47K OHM,J,1/16W
R1561 ERJ3GEYJ102 M 1K OHM,J,1/16W
R1563 ERJ3GEYJ102 M 1K OHM,J,1/16W
R1564 ERJ3GEYJ102 M 1K OHM,J,1/16W
R1589 EXB28V560J RESISTOR ARRAY
Ref.
No.
Part No. Part Name & Description Remarks
R1611 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1618 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1619 ERJ3GEYJ220 M 22 OHM,J,1/16W
R1620 ERJ3EKF5600 RESISTOR
R1621 ERJ3GEYJ220 M 22 OHM,J,1/16W
R2001 ERJ3EKF5601V RESISTOR
R2002 ERJ3EKF1871V RESISTOR
R2003 ERJ3EKF3741 RESISTOR
R2004 ERJ3EKF1132 RESISTOR
R2005 ERJ3GEYJ102 M 1K OHM,J,1/16W
R2006 ERJ3EKF5601V RESISTOR
R2007 ERJ3EKF1871V RESISTOR
R2008 ERJ3EKF3741 RESISTOR
R2009 ERJ3EKF1132 RESISTOR
R2010 ERJ3EKF5601V RESISTOR
R2011 ERJ3EKF1871V RESISTOR
R2012 ERJ3EKF3741 RESISTOR
R2013 ERJ3EKF1132 RESISTOR
R2029 ERJ3GEYJ102 M 1K OHM,J,1/16W
R2030 ERJ3GEYJ470 M 47 OHM,J,1/16W
R2031 ERJ3GEYJ101 M 100 OHM,J,1/16W
R2032 ERJ3GEYJ101 M 100 OHM,J,1/16W
R2033 ERJ3GEYJ101 M 100 OHM,J,1/16W
R2034 ERJ3GEYJ101 M 100 OHM,J,1/16W
R2035 ERJ3GEYJ331 M 330 OHM,J,1/16W
R2036 ERJ3GEYJ331 M 330 OHM,J,1/16W
R2037 ERJ3GEYJ151 M 150 OHM,J,1/16W
R2038 ERJ3GEYJ182V M 1.8KOHM,J,1/16W
R2201 EXB38V220J RESISTOR ARRAY
R9101 D0AE625JA179 RESISTOR
R9601 ERX2SJR47E M 0.47OHM,J, 2W
R9630 ERJ14YJ3R3U M 3.3 OHM,J, 1/4W
R9631 ERJ8GEYJ220 M 68 OHM, J,1/4W
R9632 ERJ14YJ5R6U M 5.6 OHM,J, 1/4W
R9633 ERJ8GEYJ100 M 10 OHM, J,1/4W
R9634 ERJ8GEYJ120 RESISTOR(B-PCB)
R9636 ERJ14YJ3R3U M 3.3 OHM,J, 1/4W
R9637 ERJ8GEYJ220 M 68 OHM, J,1/4W
R9638 ERJ14YJ5R6U M 5.6 OHM,J, 1/4W
R9639 ERJ8GEYJ100 M 10 OHM, J,1/4W
R9640 ERJ8GEYJ120 RESISTOR(B-PCB)
R9653 D0XGR22J0004 RESISTOR(B-PCB)
[CAPACITORS]
C1001 F2G1A101A029 CAPACITOR
C1002 F1G1C104A077 CAPACITOR
C1003 F1G1C104A077 CAPACITOR
C1004 F1G1C104A077 CAPACITOR
C1005 F1G1C104A077 CAPACITOR
C1006 ECJ1VF1A225Z CAPACITOR
C1007 F1G1H1020008 CAPACITOR
C1008 F1G1C104A077 CAPACITOR
C1010 F1G1C1030008 CAPACITOR
C1011 ECJ1VF1A225Z CAPACITOR
C1012 ECJ1VF1A225Z CAPACITOR
C1013 F1G1C104A077 CAPACITOR
C1014 F1G1C104A077 CAPACITOR
C1015 F1G1C104A077 CAPACITOR
C1017 F1G1C104A077 CAPACITOR
C1018 F1G1C104A077 CAPACITOR
C1019 F1G1C104A077 CAPACITOR
C1020 F1G1C104A077 CAPACITOR
C1021 F1G1C104A077 CAPACITOR
C1022 ECJ2FF1A106Z C 10UF, 10V
C1023 F1G1C1030008 CAPACITOR
C1024 F1G1C1030008 CAPACITOR
C1025 F1G1C1030008 CAPACITOR
C1026 F1G1C1030008 CAPACITOR
C1027 F1G1C104A077 CAPACITOR
C1028 ECJ2FF1A106Z C 10UF, 10V
C1029 F1G1C104A077 CAPACITOR
C1030 F1G1C104A077 CAPACITOR
76
PT-AE2000U / PT-AE2000E
