Panasonic PT-AE2000U - Page 80

Ref.
No.
Part No. Part Name & Description Remarks
C1516 F1H1C105A008 CAPACITOR
C1517 F1H1C105A008 CAPACITOR
C1518 F1H1C105A008 CAPACITOR
C1519 F1H1C105A008 CAPACITOR
C1520 F1H1C105A008 CAPACITOR
C1521 F1H1C105A008 CAPACITOR
C1522 F1H1C105A008 CAPACITOR
C1523 F1H1C105A008 CAPACITOR
C1524 F1H1C105A008 CAPACITOR
C1525 F1H1C105A008 CAPACITOR
C1526 F1H1C105A008 CAPACITOR
C1527 F1H1C105A008 CAPACITOR
C1528 F1H1C105A008 CAPACITOR
C1529 F1H1C105A008 CAPACITOR
C1530 F1H1C105A008 CAPACITOR
C1531 F1H1C105A008 CAPACITOR
C1532 F1H1C105A008 CAPACITOR
C1533 F1H1C105A008 CAPACITOR
C1534 ECJ0EB1H471K CAPACITOR
C1535 F1H1C105A008 CAPACITOR
C1536 F1H1C105A008 CAPACITOR
C1537 F1H1C105A008 CAPACITOR
C1538 F1H1C105A008 CAPACITOR
C1539 F1H1C105A008 CAPACITOR
C1540 F1H1C105A008 CAPACITOR
C1541 F1G1C104A077 CAPACITOR
C1542 F1G1C104A077 CAPACITOR
C1543 F1G1C104A077 CAPACITOR
C1544 F1G1C104A077 CAPACITOR
C1545 F1G1C104A077 CAPACITOR
C1546 F1G1C104A077 CAPACITOR
C1547 F1G1C104A077 CAPACITOR
C1548 F1G1C104A077 CAPACITOR
C1549 F1G1C104A077 CAPACITOR
C1550 F1G1C104A077 CAPACITOR
C1551 F1G1C104A077 CAPACITOR
C1552 F1G1C104A077 CAPACITOR
C1553 F1G1C104A077 CAPACITOR
C1554 F1G1C104A077 CAPACITOR
C1555 F1G1C104A077 CAPACITOR
C1556 F1G1C104A077 CAPACITOR
C1557 F2G0J3300014 CAPACITOR
C1558 F1G1C104A077 CAPACITOR
C1559 F1G1H1020008 CAPACITOR
C1560 ECJ2FF1A106Z C 10UF, 10V
C1561 F1G1H1020008 CAPACITOR
C1562 ECJ2FF1A106Z C 10UF, 10V
C1563 F1G1C104A077 CAPACITOR
C1564 F1G1C104A077 CAPACITOR
C1565 F1G1C1030008 CAPACITOR
C1567 F1H1C105A008 CAPACITOR
C1568 F1H1C105A008 CAPACITOR
C1569 F1H1C105A008 CAPACITOR
C1570 F1H1C105A008 CAPACITOR
C1571 F1H1C105A008 CAPACITOR
C1572 F1H1C105A008 CAPACITOR
C1573 F1H1C105A008 CAPACITOR
C1574 F1H1C105A008 CAPACITOR
C1575 F1H1C105A008 CAPACITOR
C1576 F1H1C105A008 CAPACITOR
C1577 F1H1C105A008 CAPACITOR
C1578 F1H1C105A008 CAPACITOR
C1579 F1H1C105A008 CAPACITOR
C2022 F1G1C104A077 CAPACITOR
C2024 F1G1C104A077 CAPACITOR
C2025 ECJ2FF1A106Z C 10UF, 10V
C2026 ECJ2FF1A106Z C 10UF, 10V
C9101 ECQU2A104MLA CAPACITOR
C9102 F1BAH1020016 CAPACITOR
C9103 F1BAH1020016 CAPACITOR
C9201 ECQU2A473MLA CAPACITOR
C9603 F0CZZ4740003 CAPACITOR(B-PCB)
C9610 F0C2E1050008 CAPACITOR(B-PCB)
Ref.
No.
Part No. Part Name & Description Remarks
C9617 F0C3C4720003 CAPACITOR
C9618 F0C2J1540007 CAPACITOR(B-PCB)
C9619 F0C2J1540007 CAPACITOR(B-PCB)
[OTHERS]
A1 K1MY84BA0200 36P CONNECTOR
A2 K1MY84BA0200 36P CONNECTOR
A3 K1MY84BA0200 36P CONNECTOR
A4 K1KA05BA0086 5P CONNECTOR
A6 K1KA15BA0051 15P CONNECTOR
A7 K1KA02BA0047 2P CONNECTOR
A8 K1KA06BA0086 2P CONNECTOR
A9 K1KA09BA0086 3P CONNECTOR
A10 K1KA03BA0086 3P CONNECTOR
A11 K1KA02BA0047 2P CONNECTOR
A12 K1KA07BA0086 3P CONNECTOR
A15 K1KA03BA0086 3P CONNECTOR
A16 K1KA03BA0047 3P CONNECTOR
A17 K1KA03BA0047 3P CONNECTOR
A18 K1KA03BA0047 3P CONNECTOR
A23 K1KA09BA0086 3P CONNECTOR
A25 K1KA03BA0047 3P CONNECTOR
H1 K1KA09AA0200 CONNECTOR
H2 K1MY06BA0007 CONNECTOR
K1 K1KA02A00626 CONNECTOR
K2 K1KA04A00633 CONNECTOR
M1 K1KA02BA0014 CONNECTOR
M2 K1KA02BA0014 CONNECTOR
R1 K1KA03BA0014 3P CONNECTOR
V1 K1KA06BA0086 CONNECTOR
CF2002 D4CC1103A037 THERMISTOR
CF2003 D4CC1103A037 THERMISTOR
F9101-1 K3GE1ZA00010 FUSE HOLDER
F9101-2 K3GE1ZA00010 FUSE HOLDER
F9101 K5D502BNA005 FUSE
HE2201 B4ABA0000009 HALL DEVICE
LF9101 G0B692J00001 LINE CHOKE
LF9102 G0B692J00001 LINE CHOKE
RM2001 B3RAD0000083 REMOTE RECEIVER PLATE
S9602 A9BZ00000013 SPARKGAP(B-PCB)
JK1001 K1CB205B0007 S-VIDEO/VIDEO IN TERMINAL
JK1002 K2HA304B0010 YPBPR1-IN TERMINAL
JK1003 K2HA304B0010 YPBPR2-IN TERMINAL
JK1005 K1FB115B0102 RGB IN 1 TERMINAL(15PIN)
JK1006 K1FA119E0004 HDMI IN TERMINAL
JK1007 K1FA119E0004 HDMI IN TERMINAL
JK1008 K1FA119E0004 HDMI IN TERMINAL
JK1009 K1FB109B0070 RS232C I/F TERMINAL(9PIN)
JK9101 TXAWC01QEXZ AC INLET ASSY
JS1004 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1005 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1006 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1007 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1012 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1013 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1020 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1021 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1022 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1023 ERJ6GEY0R00 M 0 OHM,J,1/10W
JS1024 ERJ6GEY0R00 M 0 OHM,J,1/10W
SW2001 EVQPLHA15 SWITCH
SW2002 EVQPLHA15 SWITCH
SW2003 EVQPLHA15 SWITCH
SW2004 EVQPLHA15 SWITCH
SW2005 EVQPLHA15 SWITCH
SW2006 EVQPLHA15 SWITCH
SW2007 EVQPLHA15 SWITCH
SW2008 EVQPLHA15 SWITCH
SW2009 EVQPLHA15 SWITCH
SW2010 EVQPLHA15 SWITCH
SW2011 EVQPLHA15 SWITCH
SW2012 EVQPLHA15 SWITCH
80
PT-AE2000U / PT-AE2000E
