Panasonic PT-AX100U - Page 67

Ref.
No.
Part No. Part Name & Description Remarks
74 TPEH110-1 SET COVER
TQB817002-1 SAFETY SHEET PT-AX100U
75 TQBJ0203 INSTRUCTION BOOK PT-AX100U
TQBJ0204 INSTRUCTION BOOK PT-AX100E
TQBJ7002-1 DIRECTORY SHEET PT-AX100U
TQD1712010 SHEET
TQDJ18012-2 GUARANTEE CARD(CANADA) PT-AX100U
TQDJ18026-2 GUARANTEE CARD(USA) PT-AX100U
TSXL586 FLEX CABLE(A8-S1)
52 TTPA0453 TERMINAL COVER ASSY
TUCB5061 POWERBOX INSULATION
METAL
TUCB5062 FAN INSULATION METAL
TUCB5064 ALUMINUM SHEET 1
TUCB5065 ALUMINUM SHEET 2
TUCB5066 ALUMINUM SHEET 3
TUCB5077 ALUMINUM SHEET 4
TUCB5078 ALUMINUM SHEET 5
TUCB5079 ALUMINUM SHEET 6
53 TUCX5181 GROUND METAL 1
54 TUCX5222 VASE METAL
55 TUCX5223 BOARD EARTH METAL
56 TUWC055 INSTALL METAL(K-PCB)
57 TUXX406 BALLAST INSTALL METAL
29 TXAEE03VKD3 LAMP HOUSE ASSY
23 TXAEE04VKD3 INHALATION DUCT ASSY
58 TXFKF01QDZZ BOTTOM COVER PT-AX100U
TXFKF01QEAZ BOTTOM COVER PT-AX100E
59 TXFKF02QDZZ UPPER COVER PT-AX100U
TXFKF02QEAZ UPPER COVER PT-AX100E
60 TXFKK01VKD3 LAMP COVER ASSY
61 TXFKN01VKD3 FILTER ASSY
TXJ/B1VKD3 LEAD WIRE (B1-P2)
TXJ/E2VKD3 EARTH WIRE
TXJ/E3VKD3 EARTH LEAD
TXJ/E4VKD3 EARTH LEAD
TXJ/H1VKD3 LEAD WIRE (H1-A23)
TXJ/K1VKD3 LEAD WIRE (K1-PK)
TXJ/L2VKD3 LEAD WIRE (B-PCB)
TXJ/M1VKD3 LEAD WIRE(M1-A21)
TXJ/P1VKD3 LEAD WIRE (PK-P1)
TXJ/P3VKD3 LEAD WIRE (P3-A6)
TXJ/Q3VKD3 LEAD WIRE (Q3-A4)
62 TXFEC99VKD3A OPTICALBLOCK A
TXFEC99VKD3B OPTICAL BLOCK B
63 TXFEC98VKD3 ANALYSIS BLOCK
64 TXZEC03VKD3 CINEMA FILTER ASSY
65 TXZEN01VKD3 IRIS UNIT ASSY
66 TXZKG03VKD3 LENS
XSB3+10FN SCREW
67 XSB3+8FN SCREW
XSN3+8FJK SCREW
68 XTB3+12CFN SCREW
XTBT969FJK SCREW
XTN3+6GFJ SCREW
XTW3+8PFJ SCREW
XYN2+F6FJ SCREW
XYN2+J4FJ SCREW
XYN3+F12FJ SCREW
XYN3+F30 SCREW
XYN3+F8FJ SCREW
XYN3+J12FJ SCREW
XYN3+J8FJ SCREW
XYN4+E8FJ SCREW
XYN4+F12FJ SCREW
XYN4+J12FJ SCREW
XZBT6532 POLY BAG
[INTEGRATED CIRCUIT]
IC1001 C1AB00002650 I.C
IC1005 C1AB00002628 I.C
IC1006 C3ABQJ000048 I.C
Ref.
No.
Part No. Part Name & Description Remarks
IC1007 C0ZBZ0001361 I.C
IC1010 TVRP119 I.C
IC1012 C3BBFC000321 I.C
IC1013 C0CBCBD00008 I.C
IC1016 C0EBE0000336 I.C
IC1026 C0DBEKG00004 I.C
IC1027 C0DBEYY00042 I.C
IC1028 C0DBEKG00004 I.C
IC1029 C0DBEKG00004 I.C
IC1030 C1AB00002351 I.C
IC1033 C0DBEFH00001 I.C
IC1053 C1AB00002607 I.C
IC1054 C1AB00002289 I.C
IC1055 C1AB00002607 I.C
IC1056 C1AB00002289 I.C
IC1057 C1AB00002607 I.C
IC1058 C1AB00002289 I.C
IC1060 C0CBCYG00004 I.C
IC1061 C3EBKC000014 I.C
IC1063 TVRP120 I.C
IC1066 C0CBCAG00016 I.C
IC1102 C0JBAZ002431 I.C
IC1103 C0ZBZ0001473 I.C
IC1105 C0CBCDD00004 I.C
IC1106 C3EBEC000054 I.C
IC1107 C0GBG0000053 I.C
IC1111 C0DBZGF00002 I.C
IC1115 C0ABCA000085 I.C
IC1116 C0EBE0000336 I.C
IC1117 C1BB00000888 I.C
IC1122 C0CBCAD00015 I.C
IC1123 C0CBCAD00015 I.C
IC1124 C0CBCAD00015 I.C
IC1125 C0CBCDD00004 I.C
IC1133 TVRP121 I.C
IC1137 C0JBAA000359 I.C
IC1138 C0JBAA000359 I.C
IC9602 C0ZBZ0001462 I.C(B-PCB)
IC9603 C0ZBZ0001462 I.C(B-PCB)
[TRANSISTORS]
Q1001 2SD1819A0L TRANSISTOR
Q1003 2SB1218A0L TRANSISTOR
Q1006 2SD1819A0L TRANSISTOR
Q1008 2SD1819A0L TRANSISTOR
Q1009 2SD1819A0L TRANSISTOR
Q1011 2SD1819A0L TRANSISTOR
Q1012 2SD1819A0L TRANSISTOR
Q1015 2SD1819A0L TRANSISTOR
Q1031 2SD1819A0L TRANSISTOR
Q1032 2SD1819A0L TRANSISTOR
Q1033 2SD1819A0L TRANSISTOR
Q1034 2SD1819A0L TRANSISTOR
Q1035 2SD1819A0L TRANSISTOR
Q1037 B1GBCFJJ0007 TRANSISTOR
Q1111 2SD1819A0L TRANSISTOR
Q1112 B1GBCFJJ0007 TRANSISTOR
Q1117 B1GBCFJJ0007 TRANSISTOR
Q1120 2SB1218A0L TRANSISTOR
Q1121 2SD1819A0L TRANSISTOR
Q2001 B1GDCFJJ0008 TRANSISTOR
Q2021 B1GBCFJJ0007 TRANSISTOR
Q2022 B1GBCFJJ0007 TRANSISTOR
Q2023 B1GDCFJJ0008 TRANSISTOR
Q2024 B1GDCFJJ0008 TRANSISTOR
Q9603 B1DEGQ000037 TRANSISTOR
Q9604 2SB0710AWL TRANSISTOR(B-PCB)
Q9605 2SB0710AWL TRANSISTOR(B-PCB)
Q9606 B1DEGM000022 TRANSISTOR
Q9607 B1DEGM000022 TRANSISTOR
Q9608 2SB0710AWL TRANSISTOR(B-PCB)
Q9609 2SB0710AWL TRANSISTOR(B-PCB)
67
PT-AX100U / PT-AX100E
