Panasonic PT-MZ20K

Chapter 7 Appendix — Specications
ENGLISH - 269
Signal type
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock freq.
(MHz)
Compatible signal
Horizontal
(kHz)
Vertical
(Hz)
HDMI
DIGITAL
LINK
C
640 x 480/60 640 x 480 31.5 59.9 25.2
l l
1024 x 768/50 1 024 x 768 39.6 50.0 51.9
l l
1024 x 768/60 1 024 x 768 48.4 60.0 65.0
l l
1280 x 800/50 1 280 x 800 41.3 50.0 68.0
l l
1280 x 800/60 1 280 x 800 49.7 59.8 83.5
l l
1280 x 1024/50 1 280 x 1 024 52.4 50.0 88.0
l l
1280 x 1024/60 1 280 x 1 024 64.0 60.0 108.0
l l
1366 x 768/50 1 366 x 768 39.6 49.9 69.0
l l
1366 x 768/60 1 366 x 768 47.7 59.8 85.5
l l
1400 x 1050/50 1 400 x 1 050 54.1 50.0 99.9
l l
1400 x 1050/60 1 400 x 1 050 65.2 60.0 122.6
l l
1440 x 900/50 1 440 x 900 46.3 49.9 86.8
l l
1440 x 900/60 1 440 x 900 55.9 59.9 106.5
l l
1600 x 900/50 1 600 x 900 46.4 49.9 96.5
l l
1600 x 900/60 1 600 x 900 55.9 60.0 119.0
l l
1600 x 1200/50 1 600 x 1 200 61.8 49.9 131.5
l l
1600 x 1200/60 1 600 x 1 200 75.0 60.0 162.0
l l
1680 x 1050/50 1 680 x 1 050 54.1 50.0 119.5
l l
1680 x 1050/60 1 680 x 1 050 65.3 60.0 146.3
l l
1920 x 1200/50 1 920 x 1 200 61.8 49.9 158.3
l l
1920 x 1200/60RB 1 920 x 1 200
*3
74.0 60.0 154.0
l l
*1 The signal with 1/1.001x vertical scanning frequency is also supported.
*2 YP
B
P
R
4:2:0 format only
*3 VESA CVT-RB (Reduced Blanking)-compliant
Note
f A signal with a di󰀨erent resolution is converted to the number of display dots. The number of display dots is 1 920 x 1 200.
f The “i” at the end of the resolution indicates an interlaced signal.
f When interlaced signals are connected, ickering may occur on the projected image.
f When the DIGITAL LINK connection is made with the long-reach communication method, the signal that the projector can receive is up to
1080/60p (1 920 x 1 080 dots, dot clock frequency 148.5 MHz).
f Even if it is the signal listed in the list of compatible signals, it may not be displayed by the projector if the image signal is recorded in a
special format.
