Panasonic PT-RZ790

Chapter 3 Basic Operations — Projecting
74 - ENGLISH
Projection lens
Model No.
ET-DLE020
Lens shift range
0.08 V 0.08 V
0.5 V
0.16 V
0.2 H
0.1 H
0.1 H
Standard projection position
Origin position of the lens mounter
Projected image width H
Projected image height V
Note
f
Use the projection lens in the standard projection position without adjusting the lens shift when the optional Fixed-focus Lens (Model No.:
ET-DLE055) is attached.
f
When the optional Fixed-focus Lens (Model No.: ET-DLE035) is attached, the projector can be used with the shift adjustment based on the
projected image position in the standard lens position within the range that the edge of the projected image is not blocked by the projector.
