28 - ENGLISH
For PT-TX402 and PT-TX312
All measurements below are approximate and may differ slightly from the actual measurements. (Unit: m)
Projection size 4:3 aspect ratio 16:9 aspect ratio
Screen diagonal (SD)
Projection distance
(L)
Height position
(H)
Projection distance
(L)
Height position
(H)
1.27 (50") 0.46 0.038 0.50 0.145
1.52 (60") 0.55 0.046 0.60 0.174
1.78 (70") 0.65 0.053 0.71 0.203
2.03 (80") 0.75 0.061 0.82 0.232
2.29 (90") 0.85 0.069 0.92 0.262
2.54 (100") 0.94 0.076 1.03 0.291
Projection distance formulas
To use a screen size not listed in this manual, check the screen size SD (m) and use the respective formula to calculate
projection distance.
The unit of all the formulae is m. (Values obtained by the following calculation formulae contain a slight error.)
If you want to calculate the projection distance with projected image size SD (unit: inch) by substituting, please assign 0.0254
times to the SD value.
For PT-TW342
4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen height (SH) = 0.6 × SD = 0.490 × SD = 0.530 × SD
Screen width (SW) = 0.8 × SD = 0.872 × SD = 0.848 × SD
Projection distance (L) = 0.4625 × SD - 0.0339 = 0.4188 × SD - 0.0339 = 0.4085 × SD - 0.0339
For PT-TX402 and PT-TX312
4:3 aspect ratio 16:9 aspect ratio
Screen height (SH) = 0.6 × SD = 0.490 × SD
Screen width (SW) = 0.8 × SD = 0.872 × SD
Projection distance (L) = 0.3846 × SD - 0.0339 = 0.4188 × SD - 0.0339
Chapter 2 Getting Started - Setting up
