Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)
This symbol on the products and/or accompanying documents means that used electrical and electronic products
should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these
products to designated collection points, where they will be accepted on a free of charge basis. Alternatively, in some
countries you may be able to return your products to your local retailer upon the purchase of an equivalent new
product.
Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects on human
health and the environment which could otherwise arise from inappropriate waste handling. Please contact your local authority
for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
WEEE notice/Specifications
WEEE notice
Specifications (DIN 45 500)
g AMPLIFIER SECTION
RMS output power: Dolby Digital Mode
T.H.D. 10% (Each channel driven)
1 kHz front CH 150 W per channel (6 Ω)
1 kHz surround CH 80 W per channel (4 Ω)
1 kHz center CH 80 W per channel (4 Ω)
Total RMS output power 540 W
RMS output power: STEREO Mode
T.H.D. 10%
1 kHz front CH 150 W per channel (6 Ω)
Total harmonic distortion
Half power at 1 kHz (Front CH) 0.5 % (6 Ω)
Input sensitivity
TV, DVR/DVD-P, GAME/AUX 450 mV, IHF'66
MUSIC PORT 250 mV, IHF'66
S/N at rated power (6 Ω)
TV, DVR/DVD-P, GAME/AUX 80 dB (85 dB, IHF'66)
MUSIC PORT 70 dB (85 dB, IHF'66)
Input impedance
TV, DVR/DVD-P, GAME/AUX, MUSIC PORT 47 kΩ
Tone controls
BASS 50 Hz, +10 dB to -10 dB
TREBLE 20 kHz, +10 dB to -10 dB
Load impedance
Front (L/R) 6 Ω to 8 Ω
Surround (L/R) 4 Ω to 8 Ω
Center 4 Ω to 8 Ω
g FM TUNER SECTION
Frequency range 87.50 MHz to 108.00 MHz
Sensitivity
S/N 30 dB 1.9 µV/75 Ω
S/N 26 dB 1.8 µV/75 Ω
S/N 20 dB 1.6 µV/75 Ω
IHF usable sensitivity (IHF'58) 2.2 µV/75 Ω
IHF 46 dB stereo quieting sensitivity 22 µV/75 Ω
Total harmonic distortion
MONO 0.2%
STEREO 0.3%
S/N
MONO 60 dB (71 dB, IHF)
STEREO 58 dB (65 dB, IHF)
Frequency response 20 Hz to 15 kHz, +1 dB, -2 dB
Image rejection at 98 MHz 40 dB
IF rejection at 98 MHz 70 dB
Stereo separation (1 kHz) 40 dB
Antenna terminal 75 Ω (unbalanced)
g AM TUNER SECTION
Frequency range 522 kHz to 1611 kHz (9 kHz steps)
530 kHz to 1620 kHz (10 kHz steps)
Sensitivity 500 µV/m
Selectivity (at 999 kHz) 30 dB
g GENERAL
Power supply AC 230 V to 240 V, 50 Hz
Power consumption 110 W
Dimensions (W x H x D) 430 mm x 105 mm x 385 mm
Mass 3.8 kg
Power consumption in standby mode: 1 W
Notes:
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyser.
Digital input OPTICAL 2
COAXIAL
1
4
SA-HE40(RQTV0109-1E).indb 4 2/22/2006 4:33:03 PM
