Panasonic SA-PM30MD - Page 32

Pin
No.
Mark I/O Function
78 PLL CLK I/O PLL Clock Output
79 (N.C) I/O (Open)
80 (N.C) I/O (Open)
81 TMRLED I/O Timer LED Control Out
(Timer Setting: L)
82 ASP CLOCK
OUTPUT
I/O ASP Clock Output
83 AGDATA I/O ASP Data Output
84 AGLATCH I/O ASP Latch Output
85 (N.C) I/O (Open)
86 (N.C) I/O (Open)
87 (N.C) I/O (Open)
88 (N.C) I/O (Open)
89 (N.C) I/O (Open)
90 LED 1 I/O LED Control
(active L)
Pin
No.
Mark I/O Function
91 DES1 I/O Destination Setup 1
92 DES2 I/O Destination Setup 2
93 OPEN_H I/O CD Tray Open Control
(active H)
94 CLOSE_L I/O CD Tray Close Control
(active L)
95 GND — D/A Converter Reference GND
96 (N.C) I/O (Open)
97 (N.C) I/O (Open)
98 (N.C) I/O (Open)
99 (N.C) I/O (Open)
100 VRef+ — D/A Converter Reference
Voltage
32
SA-PM30MD
