Panasonic SA-PM30MD - Page 85

18.1.2. Deck Mechanism Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CASSETTE DECK
101 RED0043 R/P HEAD BLOCK UNIT [M]
101-1 RHD17015 SCREW [M]
103 RDG0300 REEL BASE GEAR [M]
104 RDG0301 WINDING RELAY GEAR [M]
105 RDK0026 MAIN GEAR [M]
107 RDV0033-4 WINDING BELT [M]
108 RDV0034-1 CAPSTAN BELT ‘A’ [M]
110 RMB0312 TRIGGER LEVEL SPRING [M]
111 RMB0400 REEL SPRING [M]
112 RMB0403 HEAD PANEL SPRING [M]
113 RMB0404 BRAKE ROD SPRING [M]
114 RMB0406 FR LEVER SP [M]
115 RMB0408 THRUST SPRING [M]
116 RML0370 TRIGGER LEVER [M]
117 RML0371 FR LEVER [M]
118 RML0372 WINDING LEVER [M]
119 RML0374 EJECT LEVER [M]
120 RMM0131 BRAKE ROD [M]
121 RMM0133-1 EJECT ROD [M]
Ref.
No.
Part No. Part Name & Description Remarks
122 RMQ0519 REEL HUB [M]
123 RMS0398-1 MOVING CORE [M]
124 RSJ0003 PLUNGER [M]
125 RMC0061 PACK SPRING [M]
126 RXF0049 FLYWHEEL ‘F’ ASS’Y [M]
127 RXF0050 FLYWHEEL ‘R’ ASS’Y [M]
128 RXG0040 FF RELAY GEAR ASS’Y [M]
129 RMK0283A-J SUB CHASSIS [M]
130 RXL0124 PINCH ARM ‘F’ ASS’Y [M]
130-1 RMB0401 PINCH ARM SPRING ‘F’ [M]
131 RXL0125 PINCH ARM ‘R’ ASS’Y [M]
131-1 RMB0402 PINCH ARM SPRING ‘R’ [M]
132 RXL0126 WINDING ARM ASS’Y [M]
133 RXQ0412 HEAD PANEL ASS’Y [M]
133-1 RMB0405 FR ROD SPRING [M]
133-2 RMM0132 FR ROD [M]
134 RFKPXES50GCK CAP MOTOR ASS’Y [M]
135 RHD26022 MOTOR SCREW [M]
136 XTW2+5L HEAD BLOCK UNIT SCRE [M]
137 XTW26+10S SUB-CHASSIS SCREW [M]
138 XYC2+JF17 PCB EARTH SCREW [M]
139 RFKJSTR280PP CHASSIS ASS’Y [M]
85
SA-PM30MD
