Panasonic SA-PM30MD - Page 87

18.2.2. MD Mechanism Parts List
Ref.
No.
Part No. Part Name & Description Remarks
TRAVERSE DECK
401 RED0047 RECORDING HEAD [M]
402 RHD17021 NUT PLATE SCREW [M]
403 RHD17022 RECORDING HEAD SCREW [M]
404 RMC0348 THRUST SPRING [M]
405 RMC0349 NUT PLATE SPRING [M]
406 RML0515 HEAD SHIFTER [M]
407 RMQ0750 REF BASE [M]
408 RMQ0751 NUT PLATE [M]
409 RMS0611 MAIN SHAFT [M]
410 RXJ0021 DRIVE SHAFT ASS’Y [M]
411 RXK0249 MECHA CHASSIS UNIT [M]
411-1 RDV0055 BELT [M]
411-2 REM0077 TRVERSE MOTOR ASS’Y [M]
411-3 REM0078 LOADING MOTOR ASS’Y [M]
411-4 RMB0548 HOLDER SPRING [M]
Ref.
No.
Part No. Part Name & Description Remarks
411-5 RMQ0752 PIN A (BLACK) [M]
411-6 RMQ0753 PIN B (NATURAL) [M]
411-7 XQN17+C25FZ MOTOR SCREW [M]
411-8 XYC2+FF105 PCB SCREW [M]
412 RAF1700A MD OPU [M]
413 XTW2+6S SCREW [M]
414 RHD20053 SCREW [M]
415 RMB0504 DAMPER SPRING [M]
416 RMG0447-K DAMPER [M]
417 XTN17+6GFZ REF. BASE SCREW [M]
418 RML0514 LOCK LEVER [M]
419 RMM0199 SLIDER [M]
420 RMM0200 SHUTTER RUBBER [M]
421 RMR1118-K2 HOLDER [M]
422 RMB0547-1 LOCK LEVEL SPRING [M]
423 RMA1117-J MECHA BASE FRAME [M]
87
SA-PM30MD
