18.3.2. CD Mechanism Parts List
Ref.
No.
Part No. Part Name & Description Remarks
TRAVERSE DECK
301 RAE0155Z CT100 TRAVERSE [M]
302 RDG0455 TRAVERSE GEAR (A) [M]
303 RDG0456 TRAVERSE GEAR (B) [M]
304 RFKNCT100 TRAVERSE BASE ASS’Y [M]
304-1 RDG0457 LOAD GEAR (A) [M]
304-2 RDG0458 LOAD GEAR (B) [M]
304-3 RDG0459 LOAD GEAR (C) [M]
304-4 RME0290 PRESS SPRING [M]
304-5 RME0291 LOCK SPRING [M]
304-6 RML0551 TRIGGER LEVER [M]
304-7 RML0552 LOCK LEVER [M]
304-8 RMM0219 STOPPER [M]
304-9 XQN17+C28F SCREW [M]
304-10 RXQ0632 TRAVERSE MOTOR ASS’Y [M]
305 RDG0460 CAM GEAR [M]
306 RDG0461 DRIVE GEAR [M]
307 RGQ0254-K TRAY [M]
308 RHM0001 MAGNET [M]
309 RMB0603 FLOATING SPRING [M]
310 RME0288 CENTERING SPRING [M]
311 RFKNXED50-S CLAMPER HOLDER ASS’Y [M]
312 RMG0510-K FLOATING RUBBER (A) [M]
313 RMG0511-K FLOATING RUBBER (B) [M]
314 RMK0422 MECHA CHASSIS [M]
315 RMM0218 TRAVERSE DRIVE RACK [M]
316 RHD30083 SCREW (CAM GEAR) [M]
317 RMR1223-K CLAMP PLATE [M]
318 RMR1242-K FIXED PLATE [M]
319 RSH1A049-U OPEN SWITCH [M]
320 XTN2+6G SCREW [M]
321 RXQ0633 OPU UNIT [M]
