Panasonic SA-PM30MD - Page 92

18.5. Electrical Parts List
Ref.
No.
Part No. Part Name & Description Remarks
P.C.B.
REP2575A SWITCH PCB UNIT [M](RTL)
REP2807B CU100X PCB UNIT [M](RTL)
REP2857A MAIN PCB UNIT [M](RTL)
REP2858A TUNER/CASS/FL/POWER [M]EG(RTL)
REP2858D TUNER/CASS/FL/POWER [M]EB(RTL)
REP2895A-T SERVO UNIT [M](RTL)
REPX0108 R/P PCB UNIT [M](RTL)
INTEGRATED CIRCUITS
IC1 AN8772FHQ IC [M]
IC2 AN8814SB-E1 IC [M]
IC3 MN66616RA4 IC MSP LS1 [M]
IC4 AK4518VF-E2 IC AD/DA [M]
IC5 RN5RG33AA-TL IC REGULATOR [M]
IC6 TC7W04FTE12L IC [M]
IC9 RN5RZ26BA-TR IC REGULATOR [M]
IC10 MNBDF03DAA1 IC [M]
IC11 TC74HCT00AFL IC [M]
IC72 MNV4400-T8T IC 4M DRAM [M]
IC92 LB1830MS-TLM IC MOTOR DR [M]
IC101 LA1833MN-TLM IC IF & MPX [M]
IC102 LC72131MDTRM IC PLL [M]
IC401 BU4052BCF-E2 IC FUNCTION SW [M]
IC402 BH3857AFV-E2 IC SOUND PROCESSOR [M]
IC403 AN7135 IC POWER AMP [M]
IC404 AN7194K-LD IC BTC POWER [M]
IC700 M9202-01BDR3 IC FL DRIVER [M]
IC701 AN8837SBE1 IC HEAD AMP [M]
IC702 MN662790RSC IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC801 MN101C12GRB1 IC MICON [M]
IC802 TC74HCT7007A IC 3V TO 5V [M]
IC803 TC4050BF IC 5V T0 3V [M]
IC901 UPC29M33HF IC [M]
IC902 XC62CP3302TH IC 3V REGULATOR [M]
IC903 BA6283N IC MOTOR DRIVER [M]
IC971 0N2180RLC1 IC PHOTO INTERUPTOR [M]
IC1301 BA7755A IC ANALOG SW [M]
IC1302 TA8142AP IC PB/REC PRE-AMP [M]
IC1303 BA4558FE2 IC OP AMP [M]
TRANSISTORS
Q1 2SB1295-6-TB TRANSISTOR [M]
Q1 2SC1740SRTA TRANSISTOR [M]
Q2 DTC114YETL TRANSISTOR [M]
Q3 2SB1462STX TRANSISTOR [M]
Q5 2SB1295-6-TB TRANSISTOR [M]
Q6 DTC114YETL TRANSISTOR [M]
Q10 2SJ278MYTR TRANSISTOR [M]
Q11 2SK1764KYTR TRANSISTOR [M]
Q13 2SB1121ST-TD TRANSISTOR [M]
Q101 2SC2787LTA TRANSISTOR [M]
Q102 2SC2787LTA TRANSISTOR [M]
Q106 RVTDTA114EST TRANSISTOR [M]
Q401 2SC1740SRTA TRANSISTOR [M]
Q402 2SC1740SRTA TRANSISTOR [M]
Q403 RVTDTA144EST TRANSISTOR [M]
Q404 RVTDTA144EST TRANSISTOR [M]
Q405 2SC1740SRTA TRANSISTOR [M]
Q431 2SC1740SLNST TRANSISTOR [M]
Q432 2SC1740SRTA TRANSISTOR [M]
Q451 2SC1740SLNST TRANSISTOR [M]
Q501 2SC1740SRTA TRANSISTOR [M]
Q502 2SC1740SRTA TRANSISTOR [M]
Q505 2SC1740SRTA TRANSISTOR [M]
Q531 2SC1740SLNST TRANSISTOR [M]
Q532 2SC1740SRTA TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q613 RVTDTA114EST TRANSISTOR [M]
Q621 2SC1740SRTA TRANSISTOR [M]
Q671 RVTDTC143EST TRANSISTOR [M]
Q672 RVTDTC143EST TRANSISTOR [M]
Q673 2SC1740SRTA TRANSISTOR [M]
Q701 2SA1037AKSTX TRANSISTOR [M]
Q701 2SC1740SRTA TRANSISTOR [M]
Q702 2SC1740SRTA TRANSISTOR [M]
Q751 RVTDTC114EST TRANSISTOR [M]
Q754 RVTDTC114YST TRANSISTOR [M]
Q801 RVTDTC144EST TRANSISTOR [M]
Q802 2SC1740SRTA TRANSISTOR [M]
Q803 2SC1740SRTA TRANSISTOR [M]
Q804 RVTDTA143XST TRANSISTOR [M]
Q805 2SA1309ARTA TRANSISTOR [M]
Q806 RVTDTC144EST TRANSISTOR [M]
Q807 RVTDTC144EST TRANSISTOR [M]
Q808 RVTDTC144EST TRANSISTOR [M]
Q809 2SC1740SRTA TRANSISTOR [M]
Q901 2SD592ARTA TRANSISTOR [M]
Q902 2SD592ARTA TRANSISTOR [M]
Q903 2SB1566E TRANSISTOR [M]
Q904 2SC1740SRTA TRANSISTOR [M]
Q905 2SB1566E TRANSISTOR [M]
Q906 2SC1740SRTA TRANSISTOR [M]
Q907 2SC1740SRTA TRANSISTOR [M]
Q908 RVTDTA143TST TRANSISTOR [M]
Q910 2SB621ARTA TRANSISTOR [M]
Q911 2SD592ARTA TRANSISTOR [M]
Q912 RVTDTA143XST TRANSISTOR [M]
Q913 RVTDTC114YST TRANSISTOR [M]
Q914 2SA1309ARTA TRANSISTOR [M]
Q961 2SA952LTA TRANSISTOR [M]
Q962 2SC1740SRTA TRANSISTOR [M]
Q973 2SA1309ARTA TRANSISTOR [M]
Q974 2SC1740SRTA TRANSISTOR [M]
Q1101 2SJ498CTA TRANSISTOR [M]
Q1102 2SJ498CTA TRANSISTOR [M]
Q1103 2SC1740SRTA TRANSISTOR [M]
Q1104 2SC1740SRTA TRANSISTOR [M]
Q1105 2SJ498CTA TRANSISTOR [M]
Q1106 RVTDTC124TST TRANSISTOR [M]
Q1201 2SJ498CTA TRANSISTOR [M]
Q1202 2SJ498CTA TRANSISTOR [M]
Q1203 2SC1740SRTA TRANSISTOR [M]
Q1204 2SC1740SRTA TRANSISTOR [M]
Q1205 2SJ498CTA TRANSISTOR [M]
Q1206 RVTDTC124TST TRANSISTOR [M]
Q1302 2SC1845FTA TRANSISTOR [M]
Q1303 2SC2001LTA TRANSISTOR [M]
Q1304 RVTDTC114TST TRANSISTOR [M]
Q1305 2SC1740SRTA TRANSISTOR [M]
Q1306 2SC1740SRTA TRANSISTOR [M]
Q1307 2SC1740SRTA TRANSISTOR [M]
Q1308 2SC1740SRTA TRANSISTOR [M]
Q1309 2SC1740SRTA TRANSISTOR [M]
Q1310 RVTDTC114EST TRANSISTOR [M]
Q1311 RVTDTC143XST TRANSISTOR [M]
Q1313 2SC1740SRTA TRANSISTOR [M]
Q1317 RVTDTA143XST TRANSISTOR [M]
Q1318 RVTDTA143XST TRANSISTOR [M]
Q1319 2SD965RTA TRANSISTOR [M]
Q1320 2SB1030RTA TRANSISTOR [M]
Q1330 2SC1740SRTA TRANSISTOR [M]
DIODES
D1 RL1N4003N02 DIODE [M]
D2 RL1N4003N02 DIODE [M]
D3 RL1N4003N02 DIODE [M]
D4 RL1N4003N02 DIODE [M]
D5 RVD1SS133TA DIODE [M]
D5 SC80209TE12R DIODE [M]
92
SA-PM30MD
