Ref.
No.
Part No. Part Name & Description Remarks
L1 RLQU100KT-W CHIP COIL [M]
L1 RLQZ371 CHOKE COIL [M]
L2 RLQU101KT-W CHIP COIL [M]
L3 RLQU101KT-W CHIP COIL [M]
L4 RLQU2R2MT-W CHIP COIL [M]
L5 RLQU2R2MT-W CHIP COIL [M]
L6 RLQU2R2MT-W CHIP COIL [M]
L7 RLQU2R2MT-W CHIP COIL [M]
L8 RLQA2R2JT1-Y COIL [M]
L8 RLQU2R2MT-W CHIP COIL [M]
L9 RLQU100KT-W CHIP COIL [M]
L10 RLQU100KT-W CHIP COIL [M]
L11 RLQU100KT-W CHIP COIL [M]
L12 RLQU100KT-W CHIP COIL [M]
L13 RLQU2R2MT-W CHIP COIL [M]
L14 RLQU2R2MT-W CHIP COIL [M]
L15 RLQU100KT-W CHIP COIL [M]
L16 RLQU2R2MT-W CHIP COIL [M]
L17 RLQP1R8KT2-Y CHIP COIL [M]
L18 RLQP1R8KT2-Y CHIP COIL [M]
L101 ELESNR22MA CHOKE COIL [M]
L102 ELESNR22MA CHOKE COIL [M]
L103 ELEXTR47MA9 CHOKE COIL [M]
L415 RLQA100JT1-Y COIL [M]
L515 RLQA100JT1-Y COIL [M]
L601 RLL500050T-Y RF CHOKE COIL [M]
L628 RLQA2R2JT1-Y COIL [M]
L636 RLQA470JT1-Y COIL [M]
L706 RLQA2R2JT1-Y COIL [M]
L802 RLQA100JT1-Y COIL [M]
L803 RLQA100JT1-Y COIL [M]
L875 RLQA101JT1-Y COIL [M]
L877 RLL500050T-Y RF CHOKE COIL [M]
L880 RLQA101JT1-Y COIL [M]
L881 RLL500050T-Y RF CHOKE COIL [M]
L883 RLL500050T-Y RF CHOKE COIL [M]
L884 RLQA101JT1-Y COIL [M]
L911 RLL500050T-Y RF CHOKE COIL [M]
L981 RLQB470KTA-Y COIL [M]
L1301 RL08B003-K BIAS OSC COIL [M]
L1303 RLQA470JT1-Y COIL [M]
T1 RTP1M3B015-X POWER TRANSFORMER [M]
T2 RTP1I3E001-V BABY TRANSFORMER [M]
COMPONENT COMBINATION
Z1 ERZV10V511CS ZNR [M]
Z101 RLA2Z006M-T ANT COIL BLOCK [M]
Z102 RLI2Z006M-T AM IFT [M]
Z120 ENV17290G1Y FM TUNER PACK [M]
Z751 RCDRPM6937V4 REMOTE SENSOR [M]
Z801 RSL0289-F FL [M]
Z971 EXBF7L355SYV RADA RESISTOR [M]
CERAMIC FILTERS
CF201 RLFFETNGD01L CERAMIC CAPACITOR [M]
CF202 RLFFETMGD01L CERAMIC FILTER [M]
RELAY
RL1 RSY0040M-0 RELAY [M]
OSCILLATORS
X1 RSXY10M0M02T CRYSTAL [M]
X2 RSXC16M9S03T CRYSTAL [M]
X102 RLFDFT13DD CERAMIC FILTER [M]
X103 RSXD7M20C01 CRYSTAL 7.2 MHZ [M]
X701 RSXC16M9S04 CRYSTAL [M]
X801 RSXZ8M00M02T FILTER [M]
X802 RSXD32K0C01 CRYSTAL [M]
Ref.
No.
Part No. Part Name & Description Remarks
FUSE
F1 XBA2C06TB0L FUSE [M]
FUSE HOLDER
FH1 RJR0169T FUSE HOLDER [M]
FH2 RJR0169T FUSE HOLDER [M]
FUSE PROTECTOR
FP1 RSFMB50KT-L PROTECTOR [M]
FP601 RSFMB20KT-L PROTECTOR [M]
FP602 RSFMB50KT-L PROTECTOR [M]
FP871 RSFMB12KT-L COIL [M]
THERMISTOR
TH1 RRSP33J103CW THERMISTOR [M]
JACKS
JK1 SJS9236-1 JK AC IN LET [M]
JK101 RJH5210-1 JK ANTENNA [M]
JK602 RJJ36TA03-C JK [M]
JK603 RJH2206 JK RCA PIN [M]
JK604 RJJ39T01 JK MIC [M]
JK605 T0RX178A JK OPTICAL MODULE [M]
JK606 RJR0054-J JK SPEAKER TERMINAL [M]
JK607 RJH2208 JK RCA [M]
WIRES
W702 REX0996 WIRE [M]
W706 REX0985 FL TO MOTOR [M]
W1981 RWJ0102050KR MAIN-MECHA MOTOR WIR [M]
PW503 RWJ1106260QX POWER TO H.P [M]
PW704 RWJ1104240XX OPE TO REC/EDIT [M]
PW705 REX0984 V0L TO FL [M]
PW790 REX0986 CD UNIT TO MAIN [M]
PW901 REX0982 MAIN TO TRANS 8P [M]
PW902 REX0983 MAIN TO TRANS 7P [M]
PW1301 RWJ1109080QX DECK TO MAIN ( 9SP ) [M]
PW1303 RWJ1108175QX DECK TO MAIN ( 8SP ) [M]
RESISTORS
R1 ERJ3GEYJ472V 4.7K 1/16W [M]
R2 ERDS2TJ472T 4.7K 1/4W [M]
R2 ERJ3GEYJ102V 1K 1/16W [M]
R3 ERDS2TJ223T 22K 1/4W [M]
R3 ERJ3GEYJ472V 4.7K 1/16W [M]
R4 ERDS2TJ222T 2.2K 1/4W [M]
R5 ERDS2TJ2R2T 2.2 1/4W [M]
R5 ERJ3GEYJ1R0V 1 1/16W [M]
R6 ERJ3GEYJ472V 4.7K 1/16W [M]
R8 ERJ3GEYJ271V 270 1/16W [M]
R10 ERDS2TJ2R7T 2.7 1/4W [M]
R10 ERJ3GEYJ474V 470K 1/16W [M]
R11 ERDS2TJ2R7T 2.7 1/4W [M]
R11 ERJ3GEYJ101V 100 1/16W [M]
R12 ERDS2TJ222T 2.2K 1/4W [M]
R12 ERJ3GEYJ223V 22K 1/16W [M]
R13 ERD2FCVG100T 10 1/4W [M]
R13 ERJ6GEYJ3R3V 3.3 1/10W [M]
R14 ERJ3GEYD103V 10K 1/16W [M]
R15 ERJ3GEYJ223V 22K 1/16W [M]
R16 ERJ3GEYJ104V 100K 1/16W [M]
R17 ERJ3GEYJ223V 22K 1/16W [M]
R18 ERJ3GEYJ103V 10K 1/16W [M]
R19 ERJ3GEYJ102V 1K 1/16W [M]
R20 ERJ3GEYJ473V 47K 1/16W [M]
94
SA-PM30MD
