Number of channels 2 channels stereo
Wow and flutter Below measurable limit
CD Section
Sampling frequency 44.1kHz
Decoding 16 bit linear
Beam source Semiconductor laser
Wave length 780 nm
Number of channels 2 channels stereo
S/N ratio
SP OUT 70 dB (JIS A)
Wow and flutter Below measurable limit
Digital filter 8 fs
D/A converter MASH (1 bit DAC)
General
Power supply AC 220-240 V, 50/60 Hz
Power consumption (For others) 67 W
Standby 0.7 W
Dimensions (WxHxD) 180x242x287 mm
Mass 4.8 kg
Notes :
1. Specifications are subject to change without notices. Mass
and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
* US and foreign patents licensed from Dolby Laboratories
Licensing Corporation.
System: SC-PM35MD(GCS)
Music Center: SA-
PM35MD(GCS)
Speaker: SB-PM35(EG)
2001 Matsushita Electronics (S) Pte. Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. Before Repair and Adjustment
Disconnect AC power, discharge Power Supply Capacitors C607, C635 and C637 through a 10 ,
5W resistor to ground.
DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may
destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
- Current consumption at AC 240V, 50 Hz in NO SIGNAL mode
should be ~200mA.
2. Protection Circuitry
3
