The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are
“shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
1.4. Safety Parts Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by
in the Schematic Diagrams & Replacement Parts List. It is essential that these critical parts
should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the original design
without permission of manufacturer.
Table 1
Reference No. Part No. Part Name & Description Remarks
340 RAE2023Z-S TRAVERSE UNIT [M]
A2 K2CQ2CA00002 AC CORD [M] GCT
A2 K2CQ2CA00007 AC CORD [M] GC/GCP/GCS
A2 K2CT3CA00004 AC CORD [M] GS
·
SMPS Module P.C.B.:
Table 2
Reference No. Part No. Part Name & Description Remarks
40 N0AZ6GE00006 SMPS MODULE [M] (RTL)
F1 K5D502BNA005 FUSE [M]
6
SA-PT150GC / SA-PT150GCP / SA-PT150GCS / SA-PT150GCT / SA-PT150GS
