16. Terminal Function of ICs
16.1. IC941(C2CBHG000095):
System Control
Pin
No.
Terminal
Name
I/O Function
1 FL SCK O Clock signal output for IC901
2 FL CS O Chip select signal output for
IC901
3 FL RST O Reset signal output for IC901
4 DSP
DATA
O Data signal output for DSP
5 DSP
CLK
O Clock signal output for DSP
6 CNV
ss
- Connected to GND via resister
7 XC IN - Not used, open
8 XC OUT - Not used, open
9 RST I Reset signal input
10 X OUT O Ceramic oscillator connected (F
=10 MHz)
11 V
SS
- GND
12 X IN I Ceramic oscillator connected (F
=10 MHz)
13 V
CC
I Power supply terminal
14 CNT F - Connected to V
CC
via resister
15 AC IN I Power failure detect signal input
16
REMOTE
I Remote control signal input
17 DSP1
RST
O DSP reset signal output
30
