13
TQBJ2196
Attaching the main unit to a wall
The main unit can be wall mounted using the supplied wall mount brackets, etc. Make sure that the screw
used and the wall are strong enough to support the weight of at least 24 kg.
The screws and other items are not supplied as the type and size will vary with each installation.
Refer to step 3 for details about the required screws.
Be sure to attach the fall prevention cord as a secondary safety measure.
Supplied accessories
Additionally required accessories (commercially available)
Screws for wall mounting (x2)
Fall prevention cord (x2)
Screw eyes (to attach the fall prevention cord) (x2)
Note:
Use a cord that is capable of supporting over 24 kg (with a diameter of about 1.5 mm).
1 Attach the cord to the main unit.
If the cord cannot be threaded through the holes, try bending the cord, about 5 mm apart from the tip,
at an angle of 45° (as illustrated above).
WARNING:
To prevent injury, this unit must be securely attached to the wall in accordance with the installation
instructions.
2 Wall mount brackets 4 Screws
Cord
Cord
TQBJ2196_en.fm Page 13 Tuesday, February 26, 2019 6:32 PM
