Panasonic SC-HTB550 User Manual

Reference
RQT9666
31
Specifications
AMPLIFIER SECTION
RMS output power
10 % total harmonic distortion
Subwoofer ch
120 W per channel (100 Hz, 8 ≠)
Front ch (L, R ch)
60 W per channel (1 kHz, 6 ≠)
Total RMS Dolby Digital mode power
240 W
WIRELESS SECTION
Wireless module
Frequency Range 5.180 GHz to 5.240 GHz
Number of channels 4
Restriction of use For indoor use only.
TERMINAL SECTION
HDAVI Control
This unit supports “HDAVI Control 5” function.
HDMI AV input (BD/DVD, AUX1) 2
Input connector Type A (19 pin)
HDMI AV output (TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical digital input (TV, AUX2) 2
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format
LPCM, Dolby Digital, DTS
SPEAKER SECTION
Front speakers
2 way, 2 speaker system (Bass reflex type)
Speaker unit(s) Impedance 6 ≠
Woofer 6.5 cm cone typek1
Tweeter 2.5 cm semi-dome typek1
Frequency range
100 Hz to 30 kHz ( j 16 dB)
150 Hz to 25 kHz (
` 10 dB)
Active subwoofer
1 way, 1 speaker system (Bass reflex type)
Woofer 16 cm cone typek1
Frequency range 30 Hz to 180 Hz (`16 dB)
35 Hz to 160 Hz (`10 dB)
GENERAL
Power consumption Main unit: 33 W
Active subwoofer: 23 W
In standby condition Main unit: Approx. 0.2 W
Active subwoofer: Approx. 0.2 W
Power supply AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
Main unit
Cabinet dimension
310 mmk44 mmk195 mm
Maximum outer dimension
310 mmk45 mmk202 mm
Active subwoofer
180 mmk408 mmk306 mm
Mass
Main unit Approx. 1.1 kg
Active subwoofer Approx. 5.2 kg
Operating temperature range
0
o
C to i40
o
C
Operating humidity range
20 % to 80 % RH (no condensation)
SPEAKER GENERAL
Horizontal placement using the stands
Dimensions (WkHkD)
956 mmk102 mmk74 mm
Mass 1.61 kg
Horizontal placement using the speaker feet
and the support legs
Dimensions (WkHkD)
956 mmk78 mmk55 mm
Mass 1.57 kg
Horizontal placement (for wall mount)
Dimensions (WkHkD)
956 mmk75 mmk35 mm
Mass 1.54 kg
Vertical placement using the speaker bases
Dimensions (WkHkD)
148 mmk528 mmk145 mm
Mass 0.88 kg
Vertical placement (for wall mount)
Dimensions (WkHkD)
75 mmk478 mmk35 mm
Mass 0.77 kg
SC-HTB550_RQT9660_mst.book Page 31 Monday, January 30, 2012 4:53 PM

Panasonic SC-HTB550 Specifications

General

Audio decoders	Dolby Digital, Dolby Pro Logic II, DTS
RMS rated power	240 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Impedance	6 Ω
Woofer diameter	65 mm
Tweeter diameter	25 mm
Soundbar speaker RMS power	120 W
Total Harmonic Distortion (THD)	10 %
Subwoofer connectivity	Wireless
FM radio	No
Product color	Black
Recommended usage	Home theatre
Consumer Electronics Control (CEC)	VIERA Link
Apple docking compatibility	Not supported
Soundbar dimensions (WxDxH)	956 x 35 x 75 mm
Subwoofer dimensions (WxDxH)	180 x 306 x 408 mm
Connectivity technology	Wired
Digital audio optical in	1
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	50 W

Weight and Dimensions

Soundbar weight	1540 g
Subwoofer weight	5200 g
