RQT9666
7
1 Turn the main unit on or off (> 23)
2 Adjust the dialog effect level (> 23)
3 Adjust the output level of the active subwoofer
(bass sound) (> 23)
4 Adjust the volume of this system (> 23)
5 Mute the sound (> 23)
6 Select the TV as the source (> 23)
7 Select the Bluetooth
®
device as the source
(> 23)
8 Select the input source (> 23)
“TV”#“BD/DVD” #“AUX1”
^--- “”(-- “AUX2”(}
Remote control
Remove the insulation sheet A before using.
∫ To replace a button-type battery
1 While pressing the stopper B, pull out the
battery holder.
2 Set the button-type battery with its (i) mark
facing upward and then put the battery
holder back in place.
≥ When replacing the battery, use:
CR2025 (Lithium battery)
≥ Keep the button-type battery out of reach of
children to prevent swallowing.
∫ Remote control operation range
The remote control signal sensor is located on the main unit.
≥ Use the remote control within the correct operation range.
To Next Page
