Panasonic SC-PM04 User Manual

RQT9699
ENGLISH
ENGLISH
10
10
■ USB section
USB Port
USB standard USB 2.0 full speed
Media fi le format support MP3 (*.mp3)
USB device fi le system FAT12, FAT16, FAT32
USB port power 500 mA (Max)
■ Speaker section
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s)
Full range 10 cm cone type
Impedance 6
Output sound pressure 83 dB/W (1 m)
Frequency range 61 Hz to 17 kHz (–16 dB)
95 Hz to 15 kHz (–10 dB)
Dimensions (W x H x D) 139 mm x 224 mm x 136 mm
Mass 1.3 kg
■ General
Power supply AC 220 to 240 V, 50 Hz
Power consumption 12 W
Dimensions (W x H x D) 184 mm x 123 mm x 228 mm
Mass 1.1 kg
Operating temperature range 0°C to +40°C
Operating humidity range
35% to 80% RH (no condensation)
Power consumption in standby mode:
0.3 W (approximate)
1) Specifi cations are subject to change without notice.
Mass and dimensions are approximate.
2) Total harmonic distortion is measured by the digital
spectrum analyzer.
Specifi cations
■ Amplifi er section
RMS output power stereo mode
Front Ch (both ch driven)
5 W per channel (6
), 1 kHz, 10% THD
Total RMS stereo mode power 10 W
■ FM/AM tuner, terminals section
Preset station FM 30 stations
AM 15 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75
(unbalanced)
Amplitude Modulation (AM)
Frequency range 522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
Headphone jack
Terminal Stereo, 3.5 mm jack
Output level (CD, 1 kHz, –20 dB)
0.7 mW + 0.7 mW, 32
(Max)
Music port (top)
Sensitivity
Normal 490 mV, 15 k
High 100 mV, 15 k
Terminal Stereo, 3.5 mm jack
■ Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3
)
Pick up
Wavelength 790 nm (CD)
Laser power CLASS I
NORSK
Bølgelengde 790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
Audio output (Disc)
Number of channels 2 ch (FL, FR)
FL = Front left channel
FR = Front right channel
MPEG-1 Layer 3, MPEG-2 Layer 3
10
“F61” or “F76”
• Check and correct the speaker cords connection. If this
does not fi x the problem, consult the dealer.
• Disconnect the USB device. Turn the unit off and on
again.
“ERROR”
• Incorrect operation performed. Read the instructions
and try again.
“ADJUST CLOCK”
• Clock is not set. Adjust the clock accordingly.
“ADJUST TIMER”
• Play timer is not set. Adjust the play timer accordingly.
“AUTO OFF”
• The unit has been left unused for about 29 minutes and
will turn off in a minute. Press any button to cancel.
Memory reset (Initialisation)
When the following situations occur, refer to the
instructions below to reset the memory:
• There is no response when buttons are pressed.
• You want to clear and reset the memory contents.
To reset memory
1) Disconnect the AC mains lead. (Wait at least
3 minutes before proceeding to step 2.)
2) While pressing and holding down [ 1] on the
main unit, reconnect the AC mains lead.
Continue to press and hold the button
(approximately 10 seconds) until “– – – – – – – –”
is shown.
3) Release [1].
All the settings are returned to the factory preset.
You will need to reset the memory items.
SC-PM04_RQT9699-E_EC.indb 10SC-PM04_RQT9699-E_EC.indb 10 4/23/2012 5:28:05 PM4/23/2012 5:28:05 PM

Panasonic SC-PM04 Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Silver
Optical disc player	Yes
Number of optical discs	1 discs
Speaker type	-
RMS rated power	10 W
Number of speakers	2
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	45
USB 2.0 ports quantity	1
Volume control	Rotary
Power source	AC
Power consumption (standby)	0.3 W
Power consumption (typical)	12 W

Weight and Dimensions

Depth	123 mm
Width	184 mm
Height	228 mm
Weight	1100 g
