Differences from Current models
Differences from Current models
LX600
LX60
Differences from LX600/60:
1. Peaks Lite2 and VIDEO SW are introduced instead of VCTP, FPGA and Peaks Lite .
2. For LX700, HQ1L and LVDS TX are introduced for Motion Picture Pro.
3. HQ1L and LVDS TX are used to convert the picture frames from 60 to 120.
This process helps to reduce after-images.
4. The DT board of the 32LX700 provides Channel Data output only. The
MPEG2 and AC3 (Peaks Lite2) decoders are now part of the A board.
VCTP
HDMI
(CEC)
FPGA
A
ATSC
DT
AUDIO
SWITCH
LX700
LX70
Peaks Lite2
HDMI
(CEC)
HQ1L(*)
A
ATSC
DT
VIDEO
SWITCH
AUDIO
SWITCH
LVDS TX(*)
* 32LX700 only
Peaks Lite
14
