Panasonic TC-32LX70/70

Voltage Chart of AP-board
45
VOLTAGE TEST POINT SPECIFICATION CONNECTOR
24V TP7904 24.0 ± 1.2V AP2 _PIN 1, 2, 3
SUB_5V TP7211 5.12 ± 0.25V AP3_PIN 21, 22
SUB_9V TP7213 9.27 ± 0.45V AP3_PIN 8, 17, 18
BT_30V TP7601 31.5 ± 2.5V AP3_PIN 7
HQ_3.3V TP745 3.38 ± 0.17 A-Board
SOUND_15V TP7209 15.2V ± 0.75V AP3_PIN 2, 3
PANEL_12V TP7702 12.14 ± 0.6V AP4_PIN 11, 12
STB_5V TP7151 5.0 ± 0.5V AP4_PIN 3
AP-board
