Voltage Chart of DT board
47
VOLTAGE TEST POINT
A- BOARD
SPECIFICATION
SUB_3.3V TP8332 3.3 ±
0.16V
SUB_1.2V TP8328 1.26 ±
0.06V
SUB_5V TP8326 5.12 ±
0.25V
30V_A TP8331 31.5 ±
2.5V
A-board
DT-board
