Power LED Blinks 1 Time (TC
Power LED Blinks 1 Time (TC
-
-
32LX85)
32LX85)
87
Pin 5 of connector A16 should toggle low after the backlights of the LCD panel turn on. If the backlights
do not come on or pin 5 of CN A16 does not toggle low, Reseat the connectors A3, P3, and P7. Confirm the
presence of 24Vdc at pin 1 of connector P7 and 12V at pin 28 of connector A2 before replacing the LCD panel.
