Voltage Chart of P and A boards
46
VOLTAGE TEST POINT SPECIFICATION
STB3.3V TP7006 3.3 ±
0.16V
SUB1.2V TP5601 1.26 ±
0.06V
SUB1.8V TP5602 1.83 ±
0.09V
SUB3.3V TP5600 3.3 ±
0.16V
MHQ1.2V TP4209 1.22 ±
0.06V
MHQDDR2.5V TP4210 2.5 ±
0.12V
VOLTAGE TEST POINT SPECIFICATION
STB_5V TP823 5.0 ±
0.5V
P-board
A-board
