Panasonic TH-103PF9UK - Page 49

Name Test Point Voltage Volume Remarks
Vsus TPVSUS (SS) Vsus ± 0.5V VR251 (P_SS side) *
Vsus TPVSUS (SC) Vsus ± 0.5V VR251 (P_SC side) *
Ve TPVE (SS) Ve ± 1V VR6000 (SS) *
Ve2 TPVE2 (SS) 5± 1V (Fixed)
Vad TPVAD (SC2) -85V ± 1V VR6600 (SC2)
Vscn TPVSCN (SC2) Vad + 140 ± 4V VR6605 (SC2)
Vset TPVSET (SC2) 240 ± 1V VR6604 (SC2)
Vset2 TPVSET2 (SC) Vad + 8 + 1V, -0V VR6603 (SC)
Vbk TPVBK (SC2) 150 ± 1V VR6351 (SC2)
Vda TPVDA (DR1) 75 ± 1V (Fixed) (P_SC side)
Vda TPVDA (DR2) 75 ± 1V (Fixed) (P_SC side)
Vda TPVDA (DR1) 75 ± 1V (Fixed) (P_SS side)
Vda TPVDA (DR2) 75 ± 1V (Fixed) (P_SS side)
Vc TPVC (DR1) 45 ± 0.5V VR600 (DR1_SC)
Vc TPVC (DR2) 45 ± 0.5V VR650 (DR2_SC)
Vc TPVC (DR1) 34.5 ± 0.5V VR600 (DR1_SS)
Vc TPVC (DR2) 34.5 ± 0.5V VR650 (DR2_SS)
49
Driver Setup Voltages
