TH-37/42PV70F/P, TH-37/42PX70B/E
DG-BOARD PARTS LOCATION
TH-37/42PV70F/P, TH-37/42PX70B/E
DG-BOARD PARTS LOCATION
Parts Location
DG-BOARD (FOIL SIDE)
IC2000 E-5
IC4000 E-4
IC4002 E-4
IC4003 D-5
IC4004 E-4
IC4005 E-4
IC4501 G-5
IC4504 H-4
IC4506 G-5
IC4507 G-3
IC4508 F-5
IC4509 E-4
IC4513 F-5
IC4514 G-5
IC4515 G-4
IC5600 C-3
IC5601 B-3
IC5670 H-4
IC8004 B-4
IC8301 C-2
IC8408 C-3
IC8409 C-2
IC8551 H-2
IC8552 G-2
IC8601 F-3
IC8801 H-3
IC
Q1100 G-3
Q1101 G-3
Q1102 G-3
Q1103 G-2
Q1104 G-3
Q1105 G-3
Q1106 G-2
Q1107 G-3
Q1108 G-3
Q1109 G-3
Q1110 G-3
Q1111 G-3
Q4000 E-5
Q4001 E-5
Q4002 E-4
Q4200 B-6
Q4201 B-5
Q4500 H-4
Q4501 H-5
Q4502 G-5
Q4503 G-5
Q4509 H-3
Q4511 F-5
Q4512 F-5
Q4513 F-5
Q4514 F-5
Q4515 E-5
Q4516 F-5
Q4517 F-5
Q4518 E-5
Q4519 E-5
Q4521 H-5
Q4800 B-2
Q4801 A-3
Q4802 A-2
Q4803 A-3
Q4805 C-5
Q5694 F-3
Q8301 E-2
Q8403 D-3
Q8404 E-3
Q8801 H-3
Q8802 H-2
Q8850 D-4
Q8851 E-4
Q8852 E-4
Q8853 D-4
Q8913 G-4
TRANSISTOR
TP
Parts Location
DG-BOARD (COMPONENT SIDE)
IC1100 B-3
IC1101 B-4
IC4001 E-4
IC4500 C-4
IC4510 C-4
IC4800 A-3
IC5660 H-3
IC5671 B-4
IC5672 D-3
IC8001 F-4
IC8002 G-4
IC8003 G-3
IC8302 H-2
IC8401 E-3
IC8402 F-3
IC8403 E-2
IC8404 F-3
IC8405 F-2
IC8406 E-3
IC8407 E-3
IC8553 B-2
IC8554 C-2
IC8621 C-2
IC8622 C-2
IC
Q2000 B-3
Q2001 B-3
Q4504 B-6
Q4505 B-5
Q5600 G-3
Q5601 H-3
Q5602 H-3
Q5603 H-3
Q5604 H-3
Q5690 C-3
Q5691 C-3
Q5692 C-3
Q5693 D-3
Q8401 E-2
Q8402 E-2
Q8501 F-5
Q8911 B-4
Q8912 B-4
TRANSISTOR
TP1100 H-4
TP1101 G-4
TP1102 G-4
TP1103 H-1
TP1104 H-3
TP1105 G-3
TP2002 E-5
TP2003 D-5
TP2004 E-5
TP2010 E-6
TP2024 E-6
TP4200 C-6
TP4201 C-6
TP4451 A-5
TP4504 G-4
TP4505 G-5
TP4506 G-4
TP4507 G-5
TP4508 G-5
TP4513 F-4
TP4514 G-5
TP4515 F-4
TP4517 H-3
TP4518 F-4
TP4800 B-4
TP4801 B-4
TP4801 B-4
TP4802 B-4
TP4803 B-4
TP4804 B-5
TP4805 B-4
TP4806 B-4
TP4807 B-4
TP4808 B-5
TP4809 B-4
TP4810 B-4
TP4811 B-4
TP4812 B-5
TP4818 A-2
TP5600 C-3
TP5601 B-3
TP5602 B-3
TP5670 H-4
TP5707 D-6
TP5808 H-4
TP8037 B-4
TP8404 E-2
TP8601 F-3
TP8602 F-3
TP8603 F-3
TP8604 G-3
TP8605 F-3
TP8745 B-2
TP8852 G-3
TP8853 H-4
TP8854 E-3
DG
TH-37PV70F / TH-37PV70P / TH-37PX70B / TH-37PX70E / TH-42PV70F / TH-42PV70P / TH-42PX70B / TH-42PX70E
45
