5 PCB Structure sheet of GP9D chassis
Board Name Function Remarks
DA Digital Signal Processor, Micon 1
D Format Converter, Plasma AI Processor
Sub-Field Processor
1
J Slot Interface (Audio/Video/Sync input Switch),
SYNC processor, Sound processor,
1
SS Sustain drive 1
SC Scan drive 1
SU Scan out (Upper) 1
SD Scan out (Lower) 1
C1 Data Drive (Right)
C2 Data Drive (Left)
H3 Speaker terminal
S1 Power switch
V1 LED (Stand-by/Power on) & Remote receiver
V2 Key switch
P Power supply 1
HX PC / RS-232C_Input terminal
HU BNC Dual Video
HA BNC Component Video
Remarks
1: Recommend PCB´s for initial service for GP9D chassis.
8
TH-42PS9UK
