11.3. Sub bright adjustment
Instrument Name Connection Remarks
1. PAL signal generator (or RF) Connect to the input terminal User setting: Normal
Procedure Remarks
·
· ·
· Color balance adjustment is finished for each signal.
·
· ·
· Do adjustments in a dark room.
1. Display the pattern for adjusting subbright from video input.
2. Use "Sub-Bright" in the “Service-Menu1” mode to adjust so the top part of the step section
in the below diagram faintly shows up and the middle fades away.
Picture menu: Dynamic
Color balance: Normal
ASPECT: 16:9
* If using RF ch.E04,
(Sub-Bright test pattern),
adjust so the 6th section shows up and the 7th
fades away.
41
TH-42PV500A / TH-42PV500H / TH-42PV500M
