Panasonic TH-42PX600U

4. Disconnect the coupler (DT07)
5. Remove the screws (×2
).
6. Remove the DT-Board metal cover and DT-Board.
6.10. Remove the DG-Board
1. Remove the DT-Board. (See section 6.9.)
2. Remove the screws (×8
) and remove the DT-Board
metal frame.
3. Disconnect the coupler (DG2).
4. Disconnect the flexible cables (DG1, DG15 and DG20).
5. Remove the screw (×1
) remove the DG-Board.
6.11. Remove the H-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (H2, H40 and H51).
3. Disconnect the flexible cable (H1).
4. Remove the screws (×6
) and remove the H-Board.
12
TH-42PX600U
