Panasonic TH-42PX600U

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
L8204 G1C82NJA0075 INDUCTION COIL 1 PAVCA
L8205 G1C47NJ00018 INDUCTION COIL 1 PAVCA
L8207 G1C47NJ00018 INDUCTION COIL 1 PAVCA
L8208 G1CR10JA0020 INDUCTION COIL 1 PAVCA
L8209 J0JHC0000045 CHIP INDUCTOR 1
L8211 ELJNA1R0JFB INDUCTION COIL 1
L8212 G1C1R0JA0074 INDUCTION COIL 1 PAVCA
L8213,1
4
J0JHC0000045 CHIP INDUCTOR 2
L8221-
25
J0JHC0000045 CHIP INDUCTOR 5
L8231,3
2
J0JHC0000035 CHIP INDUCTOR 2
L8234,3
5
J0JHC0000045 CHIP INDUCTOR 2
L8236,3
7
J0JHC0000035 CHIP INDUCTOR 2
L8239 J0JCC0000241 CHIP INDUCTOR 1
L8241 J0JHC0000045 CHIP INDUCTOR 1
L8242 J0JCC0000078 CHIP INDUCTOR 1
L8243 ERJ3GEY0R00 M 0 OHM, 1/16W 1
L8244 J0JHC0000045 CHIP INDUCTOR 1
L8250 J0JHC0000045 CHIP INDUCTOR 1
L8253-
56
TSK1032 BEAD CHOKE 4
L8258 J0JHC0000045 CHIP INDUCTOR 1
L8264-
68
J0JHC0000045 CHIP INDUCTOR 5
L8275 J0JHC0000045 CHIP INDUCTOR 1
L8276 J0JBC0000080 CHIP INDUCTOR 1
L8279,8
0
G1CR22JA0020 INDUCTION COIL 2 PAVCA
L8281 J0JHC0000078 CHIP INDUCTOR 1
L8282-
85
J0JHC0000045 CHIP INDUCTOR 4
L8288,8
9
J0JHC0000045 CHIP INDUCTOR 2
L8290 G1C3R3ZA0083 INDUCTION COIL 1
L8291 G1C100MA0077 INDUCTION COIL 1
L8292 G1C1R5ZA0083 INDUCTION COIL 1
L8293 G1C100MA0077 INDUCTION COIL 1
L8294 J0JHC0000034 CHIP INDUCTOR 1
L8297 J0JHC0000045 CHIP INDUCTOR 1
L8298,9
9
TSK1032 BEAD CHOKE 2
L8300-
02
ERJ3GEY0R00 M 0 OHM, 1/16W 3
L8303,0
4
G1CR22JA0020 INDUCTION COIL 2 PAVCA
L8305 G1CR39JA0020 INDUCTION COIL 1 PAVCA
L8306,0
7
J0JHC0000045 CHIP INDUCTOR 2
L8308 ELJNA1R0JFB INDUCTION COIL 1
L8309 G1C56NJ00018 INDUCTION COIL 1 PAVCA
L8311 J0JHC0000045 CHIP INDUCTOR 1
L8312 TSK1032 BEAD CHOKE 1
L9500 G1C150KA0038 INDUCTION COIL 1
L9501,0
2
J0JHC0000078 CHIP INDUCTOR 2
L9800 G1C3R0MA0248 INDUCTION COIL 1
L9801,0
2
G1C2R2MA0241 INDUCTION COIL 2
L9810 J0JHC0000045 CHIP INDUCTOR 1
PA1 K1KA04AA0192 4P CONNECTOR 1
PA2 K1KA05AA0192 5P CONNECTOR 1
PA3 K1KA05AA0193 5P CONNECTOR 1
PA5 K1KA11AA0194 11P CONNECTOR 1
PA10 K1KA06A00452 6P CONNECTOR 1
PA20 K1MN40A00024 40P CONNECTOR 1
PA31-34 K1KA03AA0192 3P CONNECTOR 4
PA40 K1KA20AA0009 20P CONNECTOR 1
PA1101 K5H8012A0023 FUSE 1
PA9800 K5H4022A0023 FUSE 1
PC6480 B3PBA0000223 IC 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
PC6701-
03
B3PBA0000233 IC 3
PC6704 B3PBA0000234 IC 1
PC6705 B3PBA0000233 IC 1
PC6760 B3PBA0000223 IC 1
PC6801 B3PBA0000223 IC 1
PC6861 B3PBA0000223 IC 1
PC6871 B3PBA0000223 IC 1
Q1100-
03
2SC584500L TRANSISTOR 4
Q1106-
08
2SC584500L TRANSISTOR 3
Q1109,1
0
B1CBHD000002 FET 2
Q1111 2SC584500L TRANSISTOR 1
Q1114 2SC584500L TRANSISTOR 1
Q1116 2SC584500L TRANSISTOR 1
Q1125 2SA207700L TRANSISTOR 1
Q1130,3
1
2SC584500L TRANSISTOR 2
Q1134,3
5
2SC584500L TRANSISTOR 2
Q1137 2SC584500L TRANSISTOR 1
Q1139-
43
2SC584500L TRANSISTOR 5
Q2303 2SA207700L TRANSISTOR 1
Q2510,1
1
2SD601A TRANSISTOR 2
Q2607 2SC584500L TRANSISTOR 1
Q2608,0
9
2SD601A TRANSISTOR 2
Q2610 2SB709A TRANSISTOR 1
Q2611 2SD601A TRANSISTOR 1
Q2612 2SB709A TRANSISTOR 1
Q2613 2SC584500L TRANSISTOR 1
Q2615 2SC584500L TRANSISTOR 1
Q2617 2SC584500L TRANSISTOR 1
Q2618,1
9
2SD601A TRANSISTOR 2
Q2624 2SC584500L TRANSISTOR 1
Q2625 2SK3065T100 FET 1
Q2626 2SA207700L TRANSISTOR 1
Q2632 B1DHDC000028 TRANSISTOR 1
Q2633 2SD601A TRANSISTOR 1
Q4043,4
4
2SA207700L TRANSISTOR 2
Q4046 2SA207700L TRANSISTOR 1
Q4050 2SC584500L TRANSISTOR 1
Q4051,5
2
2SD1030 TRANSISTOR 2
Q4054 2SD1030 TRANSISTOR 1
Q4056-
59
2SA207700L TRANSISTOR 4
Q4065-
69
2SC584500L TRANSISTOR 5
Q4070,7
1
B1MBACA00008 TRANSISTOR 2
Q4082,8
3
2SK137400L TRANSISTOR 2
Q4084 B1ABDF000034 TRANSISTOR 1
Q4918,1
9
2SC584500L TRANSISTOR 2
Q4920,2
1
2SA207700L TRANSISTOR 2
Q5601 B1DHDC000028 TRANSISTOR 1
Q5602 2SD601A TRANSISTOR 1
Q5603 B1DHDC000028 TRANSISTOR 1
Q5604,0
5
2SD601A TRANSISTOR 2
Q5610 2SD601A TRANSISTOR 1
Q5613 2SD601A TRANSISTOR 1
Q5641-
43
2SA207700L TRANSISTOR 3
Q5644 2SD601A TRANSISTOR 1
Q6001-
03
B1JADN000001 TRANSISTOR 3
147
TH-42PX600U
