Panasonic TH-42PX600U

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R4286,8
7
ERJ2GE0R00 M 0.0 OHM,
J,0.063W
2
R4293 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4338-
43
ERJ2GE0R00 M 0.0 OHM,
J,0.063W
6
R4434 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4436 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4438 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4442,4
3
ERJ3EKF4220 M 422 OHM, 1/10W 2
R4444,4
5
ERJ3EKF3301 M 3.3KOHM, 1/16W 2
R4447 ERJ3EKF7680 M 768 OHM, 1/16W 1
R4449 ERJ3EKF1211 M1.21KOHM, 1/16W 1
R4450,5
1
ERJ6GEYJ821 M 820 OHM,J,1/10W 2
R4454 ERJ6GEYJ681 M 680 OHM,J,1/10W 1
R4465 ERJ2GEJ224 M 220KOHM,
J,0.063W
1
R4466,6
7
ERJ2GEJ330 M 33 OHM, J,0.063W 2
R4469 ERJ3EKF1500 M 150 OHM, 1/16W 1
R4474 ERJ3EKF1211 M1.21KOHM, 1/16W 1
R4476 ERJ2GEJ330 M 33 OHM, J,0.063W 1
R4477,7
8
ERJ6GEYJ471 M 470 OHM,J,1/10W 2
R4480 ERJ3EKF4220 M 422 OHM, 1/10W 1
R4481 ERJ3EKF2201 M 2.2KOHM, 1/16W 1
R4482,8
3
ERJ3EKF1781 M1.78KOHM, 1/16W 2
R4484,8
5
ERJ2GE0R00 M 0.0 OHM,
J,0.063W
2
R4487 ERJ3EKF5600 M 560 OHM, 1/16W 1
R4488 ERJ3EKF2201 M 2.2KOHM, 1/16W 1
R4489 ERJ6GEYJ331 M 330 OHM,J,1/10W 1
R4491 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4495 ERJ3EKF4302 M 43KOHM, 1/16W 1
R4496-
99
ERJ6GEYJ102 M 1KOHM,J,1/10W 4
R4500 ERJ3EKF2702V M27.0KOHM, 1/16W 1
R4501,0
2
ERJ6GEYJ102 M 1KOHM,J,1/10W 2
R4503 ERJ3EKF1600 M 160 OHM, 1/16W 1
R4507,0
8
ERJ2GE0R00 M 0.0 OHM,
J,0.063W
2
R4510 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4512 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4514-
16
ERJ2GE0R00 M 0.0 OHM,
J,0.063W
3
R4517 ERJ3EKF1371 M 13.7 OHM, 1/16W 1
R4519 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4520 ERJ3EKF1691 M1.69KOHM, 1/16W 1
R4521,2
2
ERJ2GEJ220 M 22 OHM, J,0.063W 2
R4523-
25
ERJ3EKF33R0 M 33 OHM, 1/16W 3
R4526 ERJ3EKF1401 M 1.4KOHM, 1/16W 1
R4527 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4528-
30
ERJ3EKF33R0 M 33 OHM, 1/16W 3
R4531 ERJ3EKF2701 M 2.7KOHM, 1/16W 1
R4532 ERJ3EKF4700 M 470 OHM, 1/16W 1
R4533 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4534,3
5
ERJ2GEJ101 M 100 OHM,
J,0.063W
2
R4536-
38
ERJ3EKF1500 M 150 OHM, 1/16W 3
R4539 ERJ3EKF1001 M 1KOHM, 1/16W 1
R4544 ERJ2GEJ220 M 22 OHM, J,0.063W 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
R4546,4
7
ERJ2GE0R00 M 0.0 OHM,
J,0.063W
2
R4548 ERJ2GEJ911X M 910 OHM,
J,0.063W
1
R4549 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4550 EXB28V220J RESISTOR ARRAY 1
R4551 ERJ2GE0R00 M 0.0 OHM,
J,0.063W
1
R4552 EXB28V220J RESISTOR ARRAY 1
R4553 ERJ2GEJ101 M 100 OHM,
J,0.063W
1
R4554 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4555 EXB28V220J RESISTOR ARRAY 1
R4556,5
7
ERJ2GEJ220 M 22 OHM, J,0.063W 2
R4560,6
1
EXB28V220J RESISTOR ARRAY 2
R4562 ERJ2GEJ560 M 56 OHM, J,0.063W 1
R4563-
65
ERJ2GEJ220 M 22 OHM, J,0.063W 3
R4566 ERJ2GEJ560 M 56 OHM, J,0.063W 1
R4567 ERJ2GEJ470 M 47 OHM, J,0.063W 1
R4568 ERJ2GEJ101 M 100 OHM,
J,0.063W
1
R4569 D1HG5608A002 NETWORK RESISTER 1
R4570,7
1
EXB28V560JX RESISTOR ARRAY 2
R4583,8
4
ERJ2GEJ390 M 39 OHM, J,0.063W 2
R4589-
04
ERJ2GEJ2R2X M 2.2OHM, J,0.063W 16
R4605,0
6
ERJ2GEJ103 M 10KOHM, J,0.063W 2
R4607 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4609,1
0
ERJ2GEJ103 M 10KOHM, J,0.063W 2
R4612,1
3
ERJ2GEJ472 M 4.7KOHM,
J,0.063W
2
R4617,1
8
ERJ2GEJ472 M 4.7KOHM,
J,0.063W
2
R4619 ERJ2GEJ473 M 47KOHM,J,0.063W 1
R4620 ERJ2GEJ560 M 56 OHM, J,0.063W 1
R4621 ERJ2GEJ473 M 47KOHM,J,0.063W 1
R4622 ERJ2GEJ560 M 56 OHM, J,0.063W 1
R4624 ERJ2GEJ560 M 56 OHM, J,0.063W 1
R4626 ERJ2GEJ560 M 56 OHM, J,0.063W 1
R4628 ERJ2GEJ103 M 10KOHM, J,0.063W 1
R4629-
32
ERJ2GEJ472 M 4.7KOHM,
J,0.063W
4
R4633,3
4
ERJ2GEJ220 M 22 OHM, J,0.063W 2
R4636 ERJ2GEJ103 M 10KOHM, J,0.063W 1
R4637 ERJ2GEJ330 M 33 OHM, J,0.063W 1
R4639 ERJ2GEJ103 M 10KOHM, J,0.063W 1
R4640 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4641 EXB28V330J RESISTOR ARRAY 1
R4642-
45
ERJ2GEJ220 M 22 OHM, J,0.063W 4
R4647 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4648 ERJ2GEJ330 M 33 OHM, J,0.063W 1
R4655 ERJ2GEJ330 M 33 OHM, J,0.063W 1
R4657 ERJ2GEJ182 M 1.8KOHM,
J,0.063W
1
R4658 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4661 ERJ2GEJ472 M 4.7KOHM,
J,0.063W
1
R4662 ERJ2GEJ220 M 22 OHM, J,0.063W 1
R4665 EXB2HV220JV RESISTOR ARRAY 1
R4667 EXB2HV220JV RESISTOR ARRAY 1
R4668 ERJ2GEJ680 M 68 OHM, J,0.063W 1
R4669 EXB2HV220JV RESISTOR ARRAY 1
R4672,7
3
ERJ2GEJ103 M 10KOHM, J,0.063W 2
R4675 ERJ3EKF1802 M 18KOHM, 1/16W 1
R4677 ERJ3EKF1802 M 18KOHM, 1/16W 1
152
TH-42PX600U
