Preset Signals
This unit can display the video signals shown in the table below.
■ Video signal
Corresponding signal
Resolution
(Dot)
Scanning frequency
Dot clock
frequency
(MHz)
Format
*3
Horizontal
(kHz)
Vertical
(Hz)
NTSC/NTSC4.43/
PAL-M/PAL60
720 × 480i 15.7 59.9 - V
PAL/PAL-N/SECAM 720 × 576i 15.6 50.0 - V
525i(480i) 720 × 480i 15.7 59.9 13.5 R/Y
625i(576i) 720 × 576i 15.6 50.0 13.5 R/Y
525i(480i) 720(1440) × 480i
*
2
15.7 59.9 27.0 D/H
625i(576i) 720(1440) × 576i
*
2
15.6 50.0 27.0 D/H
525p(480p) 720 × 480 31.5 59.9 27.0 R/Y/D/H
625p(576p) 720 × 576 31.3 50.0 27.0 R/Y/D/H
750(720)/60p 1 280 × 720 45.0 60.0 74.3 R/Y/D/H
750(720)/50p 1 280 × 720 37.5 50.0 74.3 R/Y/D/H
1 125(1 080)/60i
*
1
1 920 × 1 080i 33.8 60.0 74.3 R/Y/D/H
1 125(1 080)/50i 1 920 × 1 080i 28.1 50.0 74.3 R/Y/D/H
1 125(1 080)/24p 1 920 × 1 080 27.0 24.0 74.3 R/Y/D/H
1 125(1 080)/24PsF 1 920 × 1 080i 27.0 48.0 74.3 R/Y
1 125(1 080)/25p 1 920 × 1 080 28.1 25.0 74.3 R/Y/D/H
1 125(1 080)/30p 1 920 × 1 080 33.8 30.0 74.3 R/Y/D/H
1 125(1 080)/60p 1 920 × 1 080 67.5 60.0 148.5 R/Y/D/H
1 125(1 080)/50p 1 920 × 1 080 56.3 50.0 148.5 R/Y/D/H
■ PC signal
Corresponding signal
Resolution
(Dot)
Scanning frequency
Dot clock
frequency
(MHz)
Format
*
3
Horizontal
(kHz)
Vertical
(Hz)
VESA400 640 × 400
31.5 70.1 25.2 R/Y/D/H
37.9 85.1 31.5 R/Y/D/H
VGA 640 × 480
31.5 59.9 25.2 R/Y/D/H
35.0 66.7 30.2 R/Y/D/H
37.9 72.8 31.5 R/Y/D/H
37.5 75.0 31.5 R/Y/D/H
43.3 85.0 36.0 R/Y/D/H
SVGA 800 × 600
35.2 56.3 36.0 R/Y/D/H
37.9 60.3 40.0 R/Y/D/H
48.1 72.2 50.0 R/Y/D/H
46.9 75.0 49.5 R/Y/D/H
53.7 85.1 56.3 R/Y/D/H
MAC16 832 × 624 49.7 74.6 57.3 R/Y/D/H
852 × 480 852 × 480 31.5 59.9 34.2 D/H
XGA 1 024 × 768
39.6 50.0 51.9 D/H
48.4 60.0 65.0 R/Y/D/H
56.5 70.1 75.0 R/Y/D/H
60.0 75.0 78.8 R/Y/D/H
65.5 81.6 86.0 R/Y/D/H
68.7 85.0 94.5 R/Y/D/H
WSVGA 1 066 × 600 37.6 59.9 53.0 D/H
MXGA 1 152 × 864
53.7 60.0 81.6 R/Y/D/H
64.0 70.0 94.2 R/Y/D/H
67.5 74.9 108.0 R/Y/D/H
77.1 85.0 119.7 R/Y/D/H
MAC21 1 152 × 870 68.7 75.1 100.0 R/Y/D/H
1 280 × 720 1 280 × 720 44.8 59.9 74.5 R/Y/D/H
1 280 × 768 1 280 × 768
39.6 49.9 65.3 R/Y/D/H
47.7 60.0 80.1 R/Y/D/H
47.8 59.9 79.5 R/Y/D/H
