Storing condition
Temperature
-20 °C to 60 °C (-4 °F to 140 °F)
Humidity
20 % to 80 % (no condensation)
Connection terminals
HDMI 1
HDMI 2
TYPE A Connector ×
2
*
2
Audio signal:
Linear PCM (sampling frequencies - 48 kHz,
44.1 kHz, 32 kHz)
DVI-D IN
DVI-D 24 Pin:
Compliance with DVI Revision 1.0
Content Protection:
Compatible with HDCP 1.1
PC IN
High-Density Mini D-sub 15 Pin:
Compatible with DDC2B
Y/G:
1.0 Vp-p (75 Ω) (with sync)
0.7 Vp-p (75 Ω) (without sync)
PB/CB/B:
0.7 Vp-p (75 Ω) (without sync)
PR/CR/R:
0.7 Vp-p (75 Ω) (without sync)
HD/VD:
1.0 - 5.0 Vp-p (high impedance)
VIDEO
Audio/Video 4-pole mini jack (M3) (see page 19)
Video: 1.0 Vp-p (75 Ω)
Audio: 0.5 Vrms
AUDIO IN
Stereo mini jack (M3) 0.5 Vrms
Shared with DVI-D IN and PC IN
AUDIO OUT
Stereo mini jack (M3) 0.5 Vrms
Output: Variable (-∞ to 0 dB)
(1 kHz 0 dB input, 10 kΩ load)
SERIAL IN
External Control Terminal
D-sub 9 Pin:
RS-232C compatible
LAN
For RJ45 network connections,
compatible with PJLink
Communication method:
RJ45 10BASE-T/100BASE-TX
IR IN
Mini jack (M3)
IR OUT
Mini jack (M3)
USB
TYPE A USB connector
5V DC / 1A (USB 3.0 is not supported.)
Sound
Speakers
43/48/55-inch models:
80 mm × 30 mm × 2 pcs
65-inch model:
96 mm × 27 mm × 2 pcs
Audio Output
20 W [10 W + 10 W] (10 % THD)
Remote Control Transmitter
Power source
3 V DC (battery (AAA/R03/UM4 type) × 2)
Operating range
Approx. 7 m (22.9 ft)
(when operated directly in front of receptor)
Mass
Approx. 63 g / 2.22 ozs (including batteries)
Dimensions (W × H × D)
44 mm × 106 mm × 20.5 mm /
1.74” × 4.18” × 0.81”
*1: Environmental temperature to use this unit at
high altitudes (1 400m (4 593 ft) and higher and
below 2 800 m (9 186 ft) above sea level): 0 °C to
35 °C (32 °F to 95 °F)
*2
: VIERA LINK is not supported.
Note
●
Design and specifications are subject to change
without notice. Mass and dimensions shown are
approximate.
