71
UF-7300/7200
UF-8300/8200
3.7. Signal Waveform
3.7.1. Glossary of Electrical Abbreviations
Glossary of Electrical Abbreviations
Signal Name Function
+24V +24 VDC Power Supply
+24VA +24 VDC Power Supply
+24VIR +24 VDC Power Supply
+3.3V +3.3 VDC Power Supply
+5V +5 VDC Power Supply
+5VA +5 VDC Power Supply
+5VB +5 VDC Power Supply
+5VP +5 VDC Power Supply
+ACT ACTIVE Lamp LED Power Supply
+ALM ALARM Lamp LED Power Supply
+DAT DATA Lamp LED Power Supply
24VGND Ground
5VGND Ground
A Motor Control Signal
AA Motor Control Signal
ACL AC Power Supply (Live)
ACN AC Power Supply (Neutral)
AGND Ground
B Motor Control Signal
BB Motor Control Signal
BZCLK Buzzer Signal Output
CCLK Serial I/F Clock
CISCLK CIS Clock
CLOCK_OP CLOCK
CXD Serial Data Command
FANNERR Fan Error Detection Signal
FANPER +24VDC Fan Power
FG Ground
GND Ground
IICSCL IIC-Bus Clock
IICSDA IIC-Bus Data
KIN0 PNL Key Signal (Key Line)
KIN1 PNL Key Signal (Key Line)
KIN2 PNL Key Signal (Key Line)
KIN3 PNL Key Signal (Key Line)
KIN4 PNL Key Signal (Key Line)
KIN5 PNL Key Signal (Key Line)
KIN6 PNL Key Signal (Key Line)
KIN7 PNL Key Signal (Key Line)
L+5V +5 VDC through Process Interlock SW
L1 Telephone Line Signal
L2 Telephone Line Signal
LDADF DOOR +1.2 VDC Power Supply
LDAPNT ADF Paper Detection Sensor Signal
