How many distribution boxes are needed?
11 - 20 Rooms / Floor : Install one distribution box per each floor
301 302 303
316 317 320
201 202 203
216 217 220
3F
2F
1F
101 102 103
116 117 120
Distribution
box
Distribution
box
Distribution
box
8
Estimate
83
