Page #91 background imageLoading...
Page #91 background image
7 - 10 Rooms / Floor : Install one distribution box per two floors
301
302
303
310
201
202
203
210
101
102
103
110
3F
2F
1F
Distribution
box
Distribution
box
How many distribution boxes are needed?
8
Estimate
84
