Panasonic WRKT4504E Series - 4 Application Program; Switching; Communication Objects

Switching/Blind Actuator
10
4 Application Program
4.1 Switching
4.1.1 Communication objects
Obj.
No
Object name
Function
Size
Datapoint type
Flags
C
R
W
T
U
0
Channel 1 Switching
Switch On/off
1 Bit
[1.1] DPT_Switch




1
Channel 1 Switching
Feedback
1 Bit
[1.1] DPT_Switch




2
Channel 1 Logic
OR, AND, Lock,
Override
1 Bit
[1.1] DPT_Switch




3-8
Channel 1 reserved objects
9-107
Objects for other channels. See below table.
108
Access/Save Scene
Switching and
Blind/Shutter
1 Bit
[18.1] DPT_SceneControl




109
Central continuous
ON
Switch On/off
1 Bit
[1.1] DPT_Switch




110
Central continuous
OFF
Switch On/off
1 Bit
[1.1] DPT_Switch




111
Central Switching
Switch On/off
1 Bit
[1.1] DPT_Switch




112
Centralized Feedback
Switching
2 Bytes
[27.1]
DPT_CombinedInfoOnOff



