Panasonic WRKT4504E Series - Pulse Function and Parameters

Switching/Blind Actuator
18
4.1.2.4 Pulse Function and Parameters
Basic functionality: If the Function parameter is Pulse, then the channel works for Pulse function.
A "1" on the switching object switches the channel ON for the duration of a pulse length. If a "1" is
sent again during this switch-on phase then the channel remains switched on for the duration of a
further pulse length. If a "0" is sent during this switch-on phase then the channel switches off
immediately.
Name
Values
Description
Function
Switching
On/Off Delay
Pulse
Staircase light timer with
prewarning function
This function specifies the function type of the channel.
There are four type of selection function for each channel.
Type of contact
Normally open
Normally close
This parameter sets the contact position of each channel
at startup (i.e when mains voltage applied to the module)
Time base for pulse length
1 sec
10 sec
30 sec
1min
This parameter value is 

Factor for pulse length
(1..255 x timebase)
5255]
         

Pulse length = time base* factor
Input logic
None
Lock
And
Override
None: The channel only reacts to the switching object in
the way described at the beginning.
Lock: If the linking object is set to "1" then no pulse can
be started. The linking object has no meaning for pulses
which are already running(i.e. if it is started , it
accomplishes the pulse time, OFF and disable the
channel).
And: If the linking object is set to "0" then no pulse can be
started. The linking object has no meaning for pulses
which are already running. (i.e. if it is started , it
accomplishes the pulse time)
Override: If the linking object is set to "1" then the
channel is switched on regardless of the switching object.
Any waiting pulses are deleted during an override.
